Applying Effects
318 EDIUS - Reference Manual
Adjusting 3-Way Color Collection
1 Display the [Information] palette, and double-click [3-Way Color Correction].
Checking/Adjusting Effects
0 P346
The [3-Way Color Correction] dialog box appears.
[3-Way Color Correction] Dialog Box
0 P318
2 Adjust the balance of each color and click [OK].
[3-Way Color Correction] Dialog Box
0
(1) [Black Balance]/
[Gray Balance]/
[White Balance] Drag a point in each color to correct colors for shadow (black balance), inter-
mediate (gray balance), and highlight (white balance).
Drag the point of color wheel to adjust the hue, or move the slider to adjust
saturation and contrast.
(2) [Limit] Correct colors in the specified range.
Check [Hue], [Saturation], and [Luminance] to specify the range to adjust.
You can set the effect range by entering a value directly in each field or drag-
ging the triangle slider, or grating/slant parts.
A: Range to apply 100% adjustment
B: Range where you increase the adjustment volume gradually
C: Range where you decrease the adjustment volume gradually
(3) [Key display] View which range is applied with the effects by setting [Limit]. The area with
the effects applied 100% is displayed in white; 0% in black.
(4) [Histogram display] Display a calculated histogram for each of hue, saturation, and luminance.
(5) [ColorPicker] Select a color from the displayed image on the Player or the Recorder.
(6) Preview setting Preview setting 0 P320
(1)
(2)
(5)
(7)
(8)
(3)
(4)
(6)
A
B C
