Exporting in gxf format, P 429 – Grass Valley EDIUS Pro v.7.20 User Manual
Page 451
429
Exporting in File Formats
EDIUS - Reference Manual
Example:
If [XDCAM HD] has been selected.
3
•
If a clip is exported that does not include high-resolution or proxy data, a dialog box will appear to set the
processing before export. Select a processing method and click [OK].
• If [XDCAM MPEG IMX] was selected, 3 lines (black) will be added above and below the 720×480 video to be
exported as Even (Top Field First).
Also, 720
×576 (Odd) video will be shifted by 1 line to be exported as Even (Top Field First).
• If uploading an MXF file to an FTP server that has once been exported to a folder on a PC, use the source
browser. Click the XDCAM tree in the source browser, right-click the FTP connection destination and click
[Upload]. Select an MXF file, and click [Open].
Exporting in GXF Format
You can export a project in the GXF format employed by K2 Media Client.
3
•
To export to an FTP server, have the connection destination set in advance in system settings.
1
Note
• Audio will be exported in 16-bit format audio, even if the project preset is set to 24-bit format audio.
1 Click [K2] in the [Print to File] dialog box category tree.
Exporting Files with an Exporter
2 Select an exporter, and click [Export].
The output settings dialog box appears. The setting items will differ depending on the exporter.
[Destination]
Select whether to export to an XDCAM drive, to an FTP server, or to the
desired folder on the PC.
If [XDCAM Drive] was selected, select a Drive from the list.
If [FTP] was selected, check the server to be exported to and, as necessary,
check the item described below.
If [Folder] was selected, click [Select] and specify a save destination.
[Upload to FTP after exporting file.]
Check this item to export a temporary file to the project folder, and then
upload the actual data to an FTP server. After outputting the temporary file, if
an error occurs during transfer to the FTP server or if the upload is aborted,
the temporary file will not be deleted.
[Clip Name]
Set the file name to be exported.
If [XDCAM Drive] or [FTP] is selected as the export destination, [Auto (C****)]
will become enabled. If it is checked, a file name will be added automatically.
To set a preferred file name, remove the check from [Auto (C****)] and enter
a name in [Clip Name]. (“Clip Naming” must be set as “Free” on the XDCAM
drive side.)
If [Folder] is selected as the export destination, enter a clip name.
[Segment Encode]
Check this item to export a clip of a raw source without re-encoding. This
increases the output speed.
[Bit Rate]
Select a bitrate from the list.
[Quality/Speed]
Select a quality.
[ClosedGOP]
Check this item not to use the B-picture at the GOP border as reference
across GOPs. Although the amount of data increases, the video can be
re-edited using software that supports GOP-based editing, as the information
is completed within each GOP.
[Audio Format]
Select the audio format to export.
