Maintenance
HyIntensity Fiber Laser Instruction Manual – 807090 Revision 3 4-33
Example of voltage sourced inputs
Example of relay outputs
3.9 K
3.9 K
3.9 K
F F
F F
F F
Switch
12 VDC to 24 VDC
(external supply)
12 VDC to 24 VDC
(external supply)
12 VDC to 24 VDC
(external supply)
LED
Relay
+12 VDC to 24 VDC
(external supply)
Optoisolator Resistors
Relay
Relay
Relay
+24 V field
PTC* 100 mA
PTC* 100 mA
PTC* 100 mA
t°
t°
t°
*Positive temperature coefficient
Voltage 12 V to
24 VDC
