Signal
Direction
Description
sim_pipe_rate[1:0]
Output
The 2-bit encodings have the following meanings:
• 2’b00: Gen1 rate (2.5 Gbps)
• 2’b01: Gen2 rate (5.0 Gbps)
• 2’b1X: Gen3 rate (8.0 Gbps)
sim_pipe_pclk_in
Input
This clock is used for PIPE simulation only, and is derived from
the
refclk
. It is the PIPE interface clock used for PIPE mode
simulation.
sim_pipe_pclk_out
Output
TX datapath clock to the BFM PHY.
pclk_out
is derived from
refclk and provides the source synchronous clock for TX data
from the PHY.
sim_pipe_clk250_out
Output
Used to generate
pclk
.
sim_pipe_clk500_out
Output
Used to generate
pclk
.
sim_pipe_
ltssmstate0[4:0]
Input and
Output
LTSSM state: The LTSSM state machine encoding defines the
following states:
• 5’b00000: Detect.Quiet
• 5’b 00001: Detect.Active
• 5’b00010: Polling.Active
• 5’b 00011: Polling.Compliance
• 5’b 00100: Polling.Configuration
• 5’b00101: Polling.Speed
• 5’b00110: config.LinkwidthsStart
• 5’b 00111: Config.Linkaccept
• 5’b 01000: Config.Lanenumaccept
• 5’b01001: Config.Lanenumwait
• 5’b01010: Config.Complete
• 5’b 01011: Config.Idle
• 5’b01100: Recovery.Rcvlock
• 5’b01101: Recovery.Rcvconfig
• 5’b01110: Recovery.Idle
• 5’b 01111: L0
• 5’b10000: Disable
• 5’b10001: Loopback.Entry
• 5’b10010: Loopback.Active
• 5’b10011: Loopback.Exit
• 5’b10100: Hot.Reset
• 5’b10101: L0s
• 5’b11001: L2.transmit.Wake
