Root-Port Request Registers Address Range: 0x2800-0x2018
Address Bits Name Access Description
0x2010
[31:16] Reserved — —
[15:8] RP_RXCPL_STATUS R Specifies the number of words in the RX
completion FIFO that contain valid data.
[7:2] Reserved — —
[1] RP_RXCPL_STATUS.EOP R When 1’b1, indicates that the data for a
Completion TLP is ready to be read by the
Application Layer. The Application Layer
must poll this bit to determine when a
Completion TLP is available.
[0] RP_RXCPL_STATUS.SOP R When 1’b1, indicates that the final data for
a Completion TLP is ready to be read by
the Application Layer. The Application
Layer must poll this bit to determine when
the final data for a Completion TLP is
available.
0x2014 [31:0] RP_RXCPL_REG1 RC Lower 32 bits of a Completion TLP.
Reading frees this entry in the FIFO.
0x2018 [31:0] RP_RXCPL_REG1 RC Upper 32 bits of a Completion TLP.
Reading frees this entry in the FIFO.
Related Information
Avalon-MM Bridge TLPs on page 9-11
Uncorrectable Internal Error Mask Register
Table 5-27: Uncorrectable Internal Error Mask Register
The
Uncorrectable Internal Error Mask
register controls which errors are forwarded as internal
uncorrectable errors. With the exception of the configuration error detected in CvP mode, all of the errors are
severe and may place the device or PCIe link in an inconsistent state. The configuration error detected in CvP
mode may be correctable depending on the design of the programming software. The access code RWS stands for
Read Write Sticky meaning the value is retained after a soft reset of the IP core.
Bits Register Description Reset Value Access
[31:12] Reserved. 1b’0 RO
