Chapter 6. LIST OF DISPLAYS AND SETTING DATA
Display Item Contents Initial
value User
level Remarks
Internal Contact 3
Input assign A Same as Internal Contact Input
assign A to D.
0 to 33 4 2 Displayed when internal
contact 3 Input bit function is
function 1 to 4 (dl3.2
≠ 0).
Internal Contact 3
Input assign B 0 2
Internal Contact 3
Input assign C 0 2
Internal Contact 3
Input assign D 0 2
Internal Contact 3
Polarity A to D
1st digit: Polarity A
2nd digit: Polarity B
3rd digit: Polarity C
4th digit: Polarity D Same as Internal Contact 1 Polarity
A to D
The following setting applies to each
digit:
0: Direct
1: Reverse 0000 2
Internal Contact 3
Polarity 0: Direct
1: Reverse 0 2
Internal Contact 3
Event channel def. 0: Every Internal Event
1 to 5: Internal Event No. 0 2 Displayed when the
operation type of internal
contact 3 is timer stop/start
(dl3.1 = 17).
