Selecting and Starting a Test
42 FTB/IQS-85100G
Ethernet Test Applications
3d. Tap the protocol block 1
to configure the frame structure and its
parameters (refer to page 43).
3e. Tap the test block
2
to configure the specific test settings (refer to
page 43).
3f. Tap the clock block to configure the clock synchronization (refer
to Clock on page 67).
4. Tap the Timer tab to automatically start and/or stop the test at a given
time or for a specific duration (refer to Timer on page 157).
5. For additional test configurations refer to Test Functions on page 251.
6. Tap the Start button from the right navigation bar to start the test (refer
to Start/Stop|TX Button on page 327). The Summary result page will
be automatically displayed when the test is started from any Setup
configuration page. For additional results refer to Test Results on
page 165.
7. Depending on the test, when the test ends automatically or manually
stopped, the generate report pop-up is displayed by default. If required,
tap Yes to generate a report of the test results and statistics (refer to
Report Button on page 316 for more information).
1. Not available with Smart Loopback.
2. Not available with Traffic Gen & Mon
