Subtests and estimated time, Frame distribution – EXFO FTB/IQS-85100G Packet Blazer for FTB-500/IQS-600 User Manual
Page 124
Test Setup - Test Configurator, Timer, and System
114
FTB/IQS-85100G
RFC 2544 - Global
Subtests and Estimated Time
Subtests allows to individually enable the Throughput, Back-to-Back,
Frame Loss, and Latency subtests.
Estimated Time (H:MM) indicates the estimated time required to
complete each subtest at best conditions. The total estimated time to
complete all subtests is also displayed.
Frame Distribution
Frame Distribution allows to select either RFC 2544 (default) or User
Defined distribution.
Quantity is only available when User Defined is selected and allows to
select the number of frames, from 1 to 7 (default), in the distribution.
Frame Size (Bytes): For RFC 2544 distribution, gives predefined frame
size distribution values. For User Defined distribution, enter up to
seven frame size values.
Distribution
Frame Size
RFC 2544
64
a
,128, 256, 512, 1024, 1280, and 1518
a.
The minimum frame size will be adjusted according to the frame structure and
components selected.
User Defined
64
a
to 16000
