Form I-ZQYRA P/N 260414R5, Page 70
APPENDIX DAT, OAT, and
Wheel DAT
Sensor
Resistance
VS
Temperature
(Measuring
between yellow
wires of the
sensor.)
Temperature Resistance
(Type 24) °F °C
-10.0 -23.3 118.0K
-5.0 -20.6 100.2K
0.0 -17.8 85.35K
5.0 -15.0 72.91K
10.0 -12.2 62.48K
15.0 -9.4 53.64K
20.0 -6.7 46.23K
25.0 -3.9 39.91K
30.0 -1.1 34.56K
35.0 1.7 30.00K
40.0 4.4 26.10K
45.0 7.2 22.76K
50.0 10.0 19.90K
55.0 12.8 17.44K
60.0 15.6 15.31K
65.0 18.3 13.48K
70.0 21.1 11.88K
75.0 23.9 10.50K
77.0 25.0 10.00K
80.0 26.7 9.298K
85.0 29.4 8.250K
90.0 32.2 7.331K
95.0 35.0 6.532K
100.0 37.8 5.826K
105.0 40.6 5.209K
110.0 43.3 4.663K
115.0 46.1 4.182K
120.0 48.9 3.757K
125.0 51.7 3.381K
130.0 54.4 3.047K
135.0 57.2 2.750K
140.0 60.0 2.486K
145.0 62.8 2.251K
Option
Code Brief Description
Option
Code Brief Description
A24
High efficiency backward curved impeller fans with
ECM motors
CP5 30 Amp 240V Non-Fusible Disconnect Switch (field-installed - USA)
CP6 30 Amp 240V Fusible Disconnect Switch (field-installed - USA)
AK20 208-230 / 3ph / 60hz Supply Voltage CP7 30 Amp 600V Non-Fusible Disconnect Switch (field-installed - USA)
AK7 460 / 3ph / 60hz Supply Voltage CP8 30 Amp 600V Fusible Disconnect Switch (field-installed - USA)
BA6 Unit-Mounted, Non-fused Disconnect Switch CP17 60 Amp 240V Fusible Disconnect Switch (field-installed - USA)
BE16 Dirty Filter Alarm CP20 60 Amp 600V Fusible Disconnect Switch (field-installed - USA)
BHB7 LON Communication Module CP30 60 Amp 240V Non-Fusible Disconnect Switch (field-installed - USA)
BHB8 BacNet Communication Module CP38 60 Amp 600V Non-Fusible Disconnect Switch (field-installed - USA)
CN5 Manual On/Off Switch, 24V CP42 30 Amp 600V Fusible Disconnect Switch (field-installed - Canada)
CN7A Time Schedule Clock w/integral on/off override switch CP44 60 Amp 600V Fusible Disconnect Switch (field-installed - Canada)
CN7B CO2 Sensor (0-2000 ppm) with unit control switch
(auto/on/off)
CP59 30 Amp 600V Non-Fusible Disconnect Switch (field-installed - Canada)
CP61 60 Amp 600V Non-Fusible Disconnect Switch (field-installed - Canada)
CN7C Indoor Air Quality (VOC & CO Sensors) with unit switch
(auto/on/off)
PH1A Nominal 5kW Resistive Electric PreHeat
PH2A Nominal 10kW Resistive Electric PreHeat
CN7D Occupancy Motion Switch with integral on/off override
switch
RB5 Remote Display
Wiring Diagram
Option Identification
The Option Codes for these electrical options are shown on the wiring diagram. Cus-
tom diagram lists only the options ordered.
