Control Display Description Range Factory Default
DpCngOvrLt: Wheel Dewpoint Changeover Limit. This is the point at which the Discharge air temp swaps
between the DatSpHiDp setpoint and the DatSpLoDp setpoint.
52 - 65°F
(11-18°C)
59ºF (15°C)
DatSpHiDp: Discharge Air Temperature Setpoint with High Dewpoint . This setpoint is used when the ER
Wheel Dewpoint is greater than the DpCngOvrLt setpoint.
52 - 75°F
(11 - 24°C)
58ºF (14°C)
*DatClgSpLoDp:
Discharge Air Temperature Cooling Setpoint with Low Dewpoint. This setpoint is used when the
ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the OA temperature is greater
than the HtgClgCngOvr setpoint.
52 - 75°F
(11 - 24°C) 60ºF (15.5°C)
*DatHtgSpLoDp:
Discharge Air Temperature Heating Setpoint with Low Dewpoint. This setpoint is used when the
ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the OA temperature is less than
the HtgClgCngOvr setpoint.
52 - 75°F
(11 - 24°C)
70ºF (21°C)
DatSpDb: Sets the Discharge Air Temperature Setpoint Deadband 1 - 10 5º
OaCngOvr: Sets the Outside Air Changeover Setpoint
52 - 75°F
(11 - 24°C)
65ºF (18°C)
OaCngOvrDb: Sets the Outside Air Changeover Setpoint Deadband 1 - 10 2º
ModeCngTmr: Sets the Changeover Mode Timer 5 - 20 10 Min
ActDatSetpt: Current Active Unit Discharge Air Temperature Setpoint
↓ Menu Top Returns to the top of the menu (Page 1)
Page 2: (Only shown when Temp Control is OAReset)
↑ Previous Previous menu
DpCngOvrLt: Wheel Dewpoint Changeover Limit. The is the point at which the Discharge air temp swaps
between the DatSpHiDp setpoint and the DatSpLoDp setpoint.
52 - 65°F
(11 - 18°C)
59°F (15°C)
DatSpHiDp: Discharge Air Temperature Setpoint with High Dewpoint. This setpoint is used when the ER
Wheel Dewpoint is greater than the DpCngOvrLt etpoint.
52 - 75°F
(11 - 24°C)
58ºF (14°C)
*OaLoSpLoDp:
Outside Air Temperature Low Setpoint with Low Dewpoint. This is the Outside air Low Limit
Reset setpoint. When the OA Temp is equal to this setpoint the Unit Discharge air temperature
setpoint equals DatHiSpLoDp.
0 - 80°F
(-13 - 27°C) 50°F (10°C)
*OaHiSpLoDp:
Outside Air Temperature High Setpoint with Low Dewpoint. This is the Outside air High Limit
Reset setpoint. When the OA Temp is equal to this setpoint the Unit Discharge air temperature
setpoint equals DatLoSpLoDp.
0 - 80°F
(-13 - 27°C) 70°F (21°C)
*DaHiSpLoDp:
Discharge Air Temperature High Setpoint with Low Dewpoint. This setpoint is used when the
ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the OA temperature is equal
to the OaLoSpLoDp. DAT setpoint is reset linearly between DatHiSpLoDp and DatLoSpLoDp
setpoints.
52 - 75°F
(11 - 24°C)
70°F (21°C)
*DaLoSpLoDp:
Discharge Air Temperature Low Setpoint with Low Dewpoint. This setpoint is used when the ER
Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the OA temperature is equal to the
OaHiSpLoDp. DAT setpoint is reset linearly between DatHiSpLoDp and DatLoSpLoDp setpoints.
52 - 75°F
(11 - 24°C) 60°F (15.5°C)
DatSpDb: Sets the Discharge Air Temperature Setpoint Deadband 1 - 10 5º
ModeCngTmr: Sets the Changeover Mode Timer 5 - 20 10 Min
DatResetOutput: Current Discharge Air Temperature Reset Output
ActDatSetpt: Current Active Unit Discharge Air Temperature Setpoint
↓ Menu Top Returns to the top of the menu (Page 1)
*These sepoints will replace the DatSpLoDwPt setpoint when the control type is changed.
Page 2: (Only shown when Temp Control is HtgClgSpc)
↑ Previous Previous menu
DpCngOvrLt: Wheel Dewpoint Changeover Limit. This is the point at which the Discharge air temp swaps
between the DatSpHiDp setpoint and the DatSpLoDp setpoint.
52 - 65°F
(11 - 18°C)
59°F (15°C)
DatSpHiDp: Discharge Air Temperature Setpoint with High Dewpoint . This setpoint is used when the ER
Wheel Dewpoint is greater than the DpCngOvrLt setpoint.
52 - 75°F
(11 - 24°C)
58ºF (14°C)
*DatClgSpLoDp:
Discharge Air Temperature Cooling Setpoint with Low Dewpoint. This setpoint is used when the
ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the OA temperature is greater
than the HtgClgCngOvr setpoint.
52 - 75°F
(11 - 24°C) 60°F (15.5°C)
*DatHtgSpLoDp:
Discharge Air Temperature Heating Setpoint with Low Dewpoint. This setpoint is used when the
ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the OA temperature is less than
the HtgClgCngOvr setpoint.
52 - 75°F
(11 - 24°C)
70°F (21°C)
DatSpDb: Sets the Discharge Air Temperature Setpoint Deadband 1 - 10 5º
ZnCngOvr: Sets the Zone Changeover Setpoint
52 - 75°F
(11 - 24°C)
70°F (21°C)
ZnCngOvrDb: Sets the Zone Changeover Setpoint Deadband 1 - 10 2º
ModeCngTmr: Sets the Changeover Mode Timer 5 - 20 10 Min
ActDatSetpt: Current Active Unit Discharge Air Temperature Setpoint
↓ Menu Top Returns to the top of the menu (Page 1)
11. ALARM HISTORY MENU
Use the Esc button to get back to the Main Menu.
Control Display Description Range Factory Default
--Alarm History--
Alarm History Shows a history of the alarms. To clear history press the alarm+prg button while on the history page. Status Only
Unit DAT: Unit Discharge Air Temperature at Alarm
OAT: Outside Air Temperature at Alarm
ER DAT: Energy Recovery Wheel Discharge Air Temperature at Alarm
ER DAHum: Energy Recovery Wheel Discharge Air Humidity at Alarm
