Reznor ZQYRA Unit Installation Manual - Manual (Page 47)

Form I-ZQYRA P/N 260414R5, Page 47
Sch Cmd: Current Schedule Status
Occ Type: Current Occupancy Type 8
CN Option: Current CN Option CN5
Schedule: Sets the Schedule None / Local / BAS Local
DI Override: Sets the DI Override Off / On Off
Sensor: Sets the Sensor Type CO2 / VOC CO2
Set Sensor Type first!
↓ More More Menu Items
Page 4: (Only shown when Sensor is CO2)
--Occupancy Type 8--
Sensor: Current Sensor Type CO2
CO2 Level: Current CO2 Level Reading
CO2 Setpt: Sets the CO2 Setpoint 0 - 9999 800ppm
Off Diff: Sets the CO2 Setpoint Offset Differential 0 - 9999 50ppm
Min Runtime: Sets the Minimum Runtime 3 - 240 5 Min
Alarm: Sets the alarm Disable / Enable Enable
↓ Returns to Page 1
Page 4: (Only shown when Sensor is VOC)
--Occupancy Type 8--
Sensor: Current Sensor Type CO2
VOC Level: Current VOC Lavel Reading
VOC Setpt: Sets the VOC Setpoint 0 - 100 60%
Off Diff: Sets the VOC Setpoint Offset Differential 0 - 100 15%
Min Runtime: Sets the Minimum Runtime 3 - 240 5 Min
Alarm: Sets the alarm Disable / Enable Enable
↓ Returns to Page 1
8. FAN MENU
To access a certain menu, use up or down arrow button. At the selected Menu, press the enter button. Use the up or down arrow
button to change the value, then press the enter button. Use the Esc button to get back to the Main Menu.
Control Display Description Range Factory Default
- - Fan Menu - -
Fan Relay Cmd: Current Fan Command
SaFan Status: Current Supply Fan Status
ExFan Status: Current Exhaust Fan Status
SaFan Voltage: Current Supply Fan Voltage Output
ExFan Voltage: Current Exhaust Fan Voltage Output
SaFanSpdSetpt: Supply Fan Speed Setpoint 0 - 100% 18%
ExFanSpdSetpt: Exhaust Fan Speed Setpoint 0 - 100% 29%
9. WHEEL MENU
To access a certain menu, use up or down arrow button. At the selected Menu, press the enter button. Use the up or down arrow
button to change the value, then press the enter button. Use the Esc button to get back to the Main Menu.
Control Display Description Range Factory Default
- - Wheel Menu - -
ERWheel Cmd: Current Command of Ernergy Recovery Wheel.
ER Wheel Temp: Current Energy Recovery Wheel Discharge Air Temperature
ER Wheel Hum: Current Energy Recovery Wheel Discharge Air Humidity
ER Wheel Dewp: Current Energy Recovery Wheel Discharge Air Dewpoint
10. HEAT PUMP MENU
To access a certain menu, use up or down arrow button. At the selected Menu, press the enter button. Use the up or down arrow
button to change the value, then press the enter button. Use the Esc button to get back to the Main Menu.
Control Display Description Range Factory Default
Page 1:
--HP Menu--
HP Mode: Current Heat Pump Mode Status (Off / Heat / Cool)
Unit DA Temp: Current Unit Discharge Air Temperature
ActDatSp: Current Active Unit Discharge Air Temperature Setpoint
HP Ouput %: Current Modulation percentage output to heatpump (100% = full capacity)
HP Ouput Volt: Current Modulation voltage output to heatpump (5.0 Vdc = full capacity)
↓ Next Next menu
Page 2: (Only shown when Temp Control is Dp)
↑ Previous Previous menu
DpCngOvrLt: Energy Recovery Wheel Dewpoint Changeover Limit. This is the point at which the Discharge air
temp swaps between the DatSpHiDp setpoint and the DatSpLoDp setpoint.
52 - 65°F
(11-18°C)
59ºF (15°C)
DatSpHiDp: Discharge Air Temperature Setpoint with High Dewpoint . This setpoint is used when the Energy
Recovery Wheel Dewpoint is greater than the DpCngOvrLt setpoint.
52 - 75°F
(11 - 24°C)
58ºF (14°C)
DatSpLoDp: Discharge Air Temperature Setpoint with Low Dewpoint. This setpoint is used when the Energy
Recovery Wheel Dewpoint is lower than the DpCngOvrLt setpoint.
52 - 75°F
(11 - 24°C)
70ºF (21°C)
DatSpDb: Sets the Discharge Air Temperature Setpoint Deadband 1 - 10 5º
ModeCngTmr: Sets the Changeover Mode Timer 5 - 20 10 Min
ActDatSetpt: Current Active Unit Discharge Air Temperature Setpoint
↓ Menu Top Returns to the top of the menu (Page 1)
Page 2: (Only shown when Temp Control is HtgClgOA)
↑ Previous Previous menu
