6.0 Mechanical

(cont’d)

6.2 Inlet Air and Exhaust Air Openings (cont’d)

If equipped with optional intake and exhaust dampers, the intake damper has a motor-

ized actuator and the exhaust damper has a barometric control.
The intake damper has a 24volt, two-position, spring return actuator directly inter-

locked with the supply fan. The actuator opens the damper whenever the supply fan

is commanded to operate. When the supply fan is off, the actuator’s spring drives the

damper closed.
The exhaust hood features a low leak gravity operated back draft damper. The exhaust

damper starts to open at 0.03” w.c and is fully opened at 0.10” w.c.

6.2.4 Inlet and

Exhaust Dampers,

Option AR2Y

6.2.3 Inlet Air Hood (cont’d)

6.3 Duct

Connections

and Ductwork

Duct Connection Configuration

This unit has both vertical and horizontal supply and return air duct opening locations

so ductwork connection openings being used depend on the installation.
Installation using Horizontal Ductwork - See locations of the horizontal duct open-

ings in

FIGURE 10, page 9, and dimensions in FIGURE 1, page 4. Remove the cover

from the horizontal return air opening and re-locate it to cover the vertical return air

opening in the bottom of the cabinet. Remove and discard the cover from the hori-

zontal supply (discharge) air opening. Shipped in the carton with the hood parts (see

Paragraph 6.2), find the cover for the vertical supply air opening. Install the cover to

close the vertical supply air opening.
Installation using Vertical Ductwork - Vertical ductwork connection flanges are in the

roof curb; see

dimensions in FIGURE 8, page 8. If vertical ductwork was not installed

from the top or a field-supplied curb is used, a transition may be required for attaching

ductwork. When using vertical ductwork, the horizontal duct opening covers should not

be removed and the vertical supply duct cover shipped in the hood carton will not be

used. .

Requirements and Suggestions for Ductwork Design and Installation

Before operating the unit, be sure that the unused supply and return air openings are

closed with the covers provided.

CAUTION: An external duct system static pressure not within the

limits shown on the rating plate may overload the motors. See

Hazard Levels, page 2.

• Type of Ductwork - The type of duct installation to be used depends in part on

the construction of the roof (whether wood joist, steelbar joist, steel truss, pre-cast

concrete) and the ceiling (whether hung, flush, etc.).

• Ductwork Material - Rectangular duct should be constructed of not lighter than

No. 26 U.S. gauge galvanized iron or No. 24 B & S gauge aluminum.

• Ductwork Structure - All duct sections 24 inches (610mm) or wider, and over 48

inches (1219mm) in length, should be cross broken on top and bottom and should

have standing seams or angle-iron braces. Joints should be S and drive strip, or

locked.

• Through Masonry Walls - No supply air duct should come in contact with

masonry walls. Insulate around all air ducts through masonry walls with not less

than 1/2" (13mm) of insulation. 1" (25mm) is recommended.

• Through Uncooled/Unheated Space - Insulate all exposed supply air ducts

passing through an uncooled or unheated space with at least 1/2" (1" is

recommended) of insulation.

• Duct Supports - Suspend all ducts securely from buildings members. Do not

support ducts solely by the unit duct connections.

Indoor Installation

NOTE: If installing

this ventilation unit

indoors, exhaust and

supply airflow will be

double. Ductwork and

louvers must be sized

accordingly.
(Size 8 - CFM Range is

500-1100; Size 12 - CFM

Range is 900-1500)
Example: A Model

ZQYRA 12 installed

indoors operating at

1500 cfm will require

supply and exhaust

ductwork sized for 3000

cfm.

hood top flange under the edge of the cabinet top. (If needed, loosen the screw

in the cabinet top.) Matching holes, attach the hood on both sides and across the

top.

To complete the installation, slide the filter

(M) in place and attach the filter access

panel

(K).
