Form I-ZQYRA P/N 260414R5, Page 3
DANGER
The heat pump in this ventilation unit is designed to use R-410A high pressure
refrigerant only. Hazards exist that could result in personal injury or death.
Installation, maintenance, and service should only be performed by an HVAC
technician qualified in R-410A refrigerant and using proper tools and equipment.
Due to much higher pressure of R-410A refrigerant, DO NOT USE service equipment
or tools designed for R22 refrigerant.
DANGER
Never use oxygen to pressurize a refrigeration system. Oxygen can explode on
contact with oil and result in personal injury or death. When using high pressure
gas such as nitrogen for pressurizing a refrigeration system, ALWAYS USE A
PRESSURE REGULATOR that can control the pressure down to 1 or 2 psig.
SAFETY WARNINGS
For your safety, wear eye protection, gloves, and protective clothing when handling
R-410A refrigerant or POE oil and when brazing. Have a fire extinguisher nearby
when brazing.
DANGER
Before installing or servicing, always turn off the main power to the system and
install a lock out on the disconnect switch.
1.2 General
Information
This booklet includes installation, operation, maintenance, and service information.
Before beginning any procedure, carefully review the information, paying particular
attention to the warnings. All installations must be in compliance with all codes and
requirements of authorities having jurisdiction.
1.3 Warranty Refer to limited warranty information on the Warranty Form in the “Literature Bag”
shipped with this system.
1.4 Installation
Codes
All installations must be in compliance with the National Electric Code ANSI/NFPA No.
70 (latest edition) or, in Canada, the Canadian Electrical Code, Part I-C.S.A. Standard
C 22.1. Check any local ordinances or utility company requirements that apply. The
installation must be in compliance with all authorities having jurisdiction. Local code
requirements supersede national requirements.
2.0 Location This ventilation unit is designed to be mounted outdoors on a level surface but could
be mounted indoors. The supporting structure must be able to support the operating
weight of the unit and maintain a level plane during continued operation. Water should
drain away from the unit. Location must comply with free space clearances for unre-
stricted airflow
3.0 Receiving,
Moving, and
Uncrating
3.1 Receiving
Check for any damage that may have happened during shipment. If damage is found,
document the damage with the transporting agency and immediately contact your
Reznor ® distributor. If you are an authorized Distributor, follow the FOB freight policy
procedures as published by Reznor, LLC.
3.2 Storage and
Moving
With the shipping skid attached, the unit may be moved with a fork lift or an overhead
crane. After the shipping skid has been removed, the unit must be lifted from overhead.
The heavy gauge base of the ventilation unit has a lifting lug on each corner. Always
use spreader bars when rigging to prevent damage to the cabinet.
