Form I-UD-V-PV, P/N 195675R12, Page 1
APPLIES TO
: Venting Requirements
for Indoor, Power Vent
Model UDAP and Model UDBP
Form I-UD-V-PV (Version D.1)
Obsoletes I-UD-V-PV (Version D) ®
General
WARNING
Each heater requires its own individual vent pipe run and
vent cap. Manifolding of vent runs can cause recirculation
of combustion products into the building. Failure to comply
could result in severe personal injury or death and/or
property damage.
WARNING
Installation should be done by a qualified agency in
accordance with these instructions. The qualified service
agency installing this heater is responsible for the
installation.
This manual applies only to venting instructions and must be used with the installation
manual. Both manuals are shipped with the heater. If either manual is missing, contact
your distributor before beginning installation. The instructions in this manual apply to
fan type Model UDAP and blower type Model UDBP.
Verify that the label near the vent outlet on the heater matches the label illustrated
below. (Label P/N is 201214; color is red.)
POWER
VENT
201214
Rear View - Model UDAP
CAUTION: Model UDAP and UDBP unit heaters should not be used
in an application where the heated space temperature is below
50°F (10°C). Operating under low ambient conditions may cause
condensate to form in the heat exchanger.
