Form I-ZQYRA P/N 260414R5, Page 41
Page 3: (Only shown when Protocol is BACnet MSTP)
-- MSTP SETUP --
Press “←┘” to retrieve current data! [0 - 4194] [0 - 999]
Instance: Sets the Instance 9600 / 19200 / 38400 / 76800
Baudrate: Sets the Baudrate 0 - 127
MAC Addr: Sets the MAC Address 0 - 127
MaxMasters Sets the MaxMasters 0 - 127
Press "Prg" to save changes. When complete, cycle power.
↓ Return to the top of the menu (Page 2)
Page 3: (Only shown when Protocol is BACnet IP/Eth)
-- MSTP SETUP --
Press “←┘” to retrieve current data! [0 - 9999] [0 - 999]
Instance: Sets the Instance [0 - 255] [0 - 255] [0 - 255] [0 - 255]
STATIC IP: Sets the Static IP Address 0 - 127
SubNet: Sets the SubNet Address 000.000.000.00 / 255.000.000.00 / 255.255.000.00 / 255.255.255.00
Gtwy: Sets the Gateway [0 - 255] [0 - 255] [0 - 255] [0 - 255]
DNS1: Sets the DNS2 [0 - 255] [0 - 255] [0 - 255] [0 - 255]
DNS2: Sets the DNS2 [0 - 255] [0 - 255] [0 - 255] [0 - 255]
Type: Sets the Type IP / Eth
Press "Prg" to save changes. When complete, cycle the power.
↓ Return to the top of the menu (Page 2)
Page 3: (Only shown when Protocol is MODBUS EXT)
--BMS Config Menu--
BMS PORT 1
Address Sets Controller Address. 0 - 999
Baud Rate Sets the Baud Rate 1200 / 2400 / 4800 / 9600 / 19200
Address Sets the address2 1 - 207
↓ Return to the top of the menu (Page 2)
Page 2: (Only shown when Controller is selected)
-- Controller--
Software Version: Current Software version (Version number and date)
Hardware Info:
Bios: Bios Version (Version number and date)
Boot: Boot Version (Version number and date)
↓ Next Menu
Page 3: (Only shown when Controller is selected)
-- Controller --
Board Type: Current Board Type
Board Size: Current Board Size
Total Flash: Total amount of installed flash
RAM: Total amount of installed RAM
Built_In type: Built in memory type.
Main Cycle: Program cycles per second.
↓ Return to the top of the menu (Page 2)
6E. Config Menu
To access a certain menu, use the up or down arrow button. At the selected Menu, press the enter button. Use the Esc button to get
back to the Service Menu .
Control Display Description Range Factory Default
Page 1:
--Config Menu--
Current Config Opens Current Configuration Menu
Current A.i.n Opens Current AIN Menu
Edit Equip Config Opens edit Equipment Configuration Menu
Edit Alarm Config Open alarm Configuration Menu
Edit Sensor Config Opens Sensor Configuration Menu
Page 2: (Only shown when Current Cnfg is selected)
--Current Config Menu--
Units: Current units
Fan Option: Current Fan option Installed
Fan Type: Current Fan Type (SA/EA)
Control Option: Current CN option
Preheat: Preheat Installed
Temp Control: Current temperature control option.
Press the Esc button to go back to Page 1
Page 2: (Only shown when Current A.i.n is selected)
--Current AIN--
Not Available
Press the Esc button to go back to Page 1
Page 2: (Only shown when Edit Equip Config is selected)
--Edit Equip Config--
Unit Of Measure: Sets the unit of meaurement US or SI SI
Temp Control: Sets the Temperature Control type Dp / HtgClgOA / OAReset / HtgClgSpc Dp
PreHeat Installed?: Sets the Preheat installed command No / Yes No
