6F. Calibration Menu
To access a certain menu, use up or down arrow. At the selected Menu, press the enter button. Use the up or down arrow to change
the value, then press the enter button. Use the Esc button to get back to the Service Menu.
Control Display Description Range Factory Default
Page 1:
--Calibration Menu--
OA Temp: Current Outside Air Temperature Status Only
Offset: OA Temperature Offset +/- 20 0º
ER Wheel Temp: Current Energy Recovery Wheel Discharge Air Temperature Status Only
Offset: Energy Recovery Wheel DA Temperature Offset +/- 20 0º
↓ Next Next menu
Page 2:
ER Wheel Hum: Current Energy Recovery Wheel Humidity Status Only
Offset: Energy Recovery Wheel Humidity Offset +/- 20 0º
Unit DA Temp: Current Unit Discharge Air Temperature Status Only
Offset: Unit DA Temperature Offset +/- 20 0º
↓ Next Next menu
Page 3: (Only shown when Space Temperature Sensor installed and activated)
Zone Temp: Current Zone Space Temperature (Only shown when applicable) Status Only
Offset: Zone Space Temperature Offset +/- 20 0º
↓ Next Next menu
Page 3: (Only shown when sensors installed and activated)
CO2: Current Carbon dioxide Level (Only shown when applicable) Status Only
Offset: Carbon dioxide Level offset (Only shown when applicable) +/- 200 0 ppm
VOC: Current VOC Level (Only shown when applicable) Status Only
Offset: VOC Level offset (Only shown when applicable) +/- 20 0%
↓ Menu Top Returns to the top of the menu
Control Display Description Range Factory Default
Space Temp Fail: Sets the Space Temperature Failure Alarm Yes / No Yes
Comp DA Limits: Sets the Compressor Discharge Air Limit Alarm Yes / No No
↓ Menu Top Returns to the top of the menu
Press the Esc button to go back to Page 2
Page 2: (Only shown when Edit Sensor Config is selected)
--Edit Sensors--
Sensor Type: Sets the Sensor Type None/CO2/VOC
Sensor Cntrl: Sensor Control Status Monitor / Cntrl Cntrl
↓ Configure ↓Configure ( 3)
Press the Esc button to go back to Page 1
Page 3: (Only shown when Sensor Type is CO2)
--Edit CO2 Sensor--
Sensor Type: Sensor Type Installed 0-5 VDC
LoRange(PPM): Sets the Sensor Low Range (PPM) 0 - 32767 0
HiRange(PPM): Sets the Sensor High Range (PPM) 0 - 32767 2000
Setpoint: Sets the CO2 Setpoint 0 - 9999 800 ppm
Off Diff: Sets the CO2 Setpoint Offset Differential 0 - 999 50 ppm
Sensor Alm: Sets the CO2 Sensor Alarm Yes / No No
↓ Returns to Page 2
Press the Esc button to go back to Page 1
Page 3: (Only shown when Sensor Type is VOC)
--Edit VCO Sensor--
Sensor Type: Sensor Type Installed 0-5 VDC
LoRange(PPM): Sets the Sensor Low Range (PPM) 0 - 32767 0
HiRange(PPM): Sets the Sensor High Range (PPM) 0 - 32767 100
Setpoint: Sets the VOC Setpoint 0 - 100 60%
Off Diff: Sets the VOC Setpoint Offset Differential 0 - 99 15%
Sensor Alm: Sets the VOC Sensor Alarm Yes / No No
↓ Returns to Page 2
Press the Esc button to go back to Page 1
6G. SETPT DEFAULTS MENU
To access a certain menu, use up or down arrow button. At the selected Menu, press the enter button. Use the up or down arrow
button to change the value, then press the enter button. Use the Esc button to get back to the Service Menu.
Control Display Description Range Factory Default
--Setpoint Defaults--
Page 1:
Save Current Setpts: This allows the user to save the current setpoints to the controller. No / Yes No
Restore Saved Setpts: This allows the user to restore the last saved setpoints in the controller. No / Yes No
↓ Next Next menu
Page 2:
Restore Test and Balance (TAB)
saved Fan Setpoints:
This allows the user to restore the supply air and exhaust air fan speed to
the last saved TAB fan setpoints in the controller.
No / Yes No
