Form I-ZQYRA P/N 260414R5, Page 42
Control Display Description Range Factory Default
Space Temp: Sets the Space Temperature sensor Disable / Enable Disable
Press the Esc button to go back to Page 1
Page 2: (Only shown when Edit Alarm Config is selected)
--Edit Alarm Menu--
Fan Failure Alarm Opens Fan Failure Alarm Menu
HP General Alarm Opens HP General Alarm Menu
Unit Shutdown DI Opens Unit Shutdown DI Menu
Cripple Mode Opens Cripple Mode Alarm Menu
CO2/VOC Alarm Opens CO2/VOC Alarm Menu
Low Limit Alarm Opens Low Limit Alarm Menu
High OA Tem Alarm Opens High OA Temp Alarm Menu
Defrost Opens Defrost Menu
Reversing Vlv Alm Open Reversing Valve Alarm Menu
RestartShutdown Opens Restart/Shutdown Menu
BAS Shutdown Open BAS Shutdown Alarm Menu
Alarm Output (DO) Open Alarm Output (DO) Menu
Page 3: (Only shown when Fan Failure Alarm is selected)
--Fan Failure Alarm--
Fan Proof Alarms
FanFailureTimer: Sets the Fan Failure Timer 60 - 600 s 120 s
DI1 SaFan Sw: DI1 Supply Air Fan Switch Status Off / On
SaFan Alarm: Supply Air Fan Alarm Status Alarm / Normal
DI2 ExFan Sw: DI2 Exhaust Air Fan Switch Status Off / On
ExFan Alarm: Exhaust Air Fan Alarm Status Alarm / Normal
↓ Next Next menu
Press the Esc button to go back to Page 2
Page 4: (Only shown when Fan Failure Alarm is selected)
Fan DI General Alarms
FanGenAlm Delay: Sets the Fan General Alarm Delay Timer 30 - 600 s 60 s
DI6 Fan Alm: DI6 Fan Alarm Status Alarm / Normal
Alarm Status: Alarm Status Alarm / Normal
↓ Menu Top Returns to the top of the menu
Press the Esc button to go back to Page 2
Page 3: (Only shown when HP Failure Alarm is selected)
HP General Alarm
HP GenAlm Delay: Sets the Heat Pump General Alarm Delay Timer 60 - 600 s 80 s
DI4 HP Alarm: DI4 Heat Pump Alarm Status Alarm / Normal
Alarm Status: Alarm Status Alarm / Normal
Press the Esc button to go back to Page 2
Page 3: (Only shown when Unit Shutdown DI is selected)
Unit Shutdown DI
Shutdown Clear: Sets the Shutdown Clear Timer 60 - 600 Sec 60 s
Shtdwn DI: DI5 Shutdown Alarm Status Alarm / Normal -
Remaining Time: Remaining Time Status 60 - 600 Sec- -
Press the Esc button to go back to Page 2
Page 3: (Only shown when Cripple Mode is selected)
Cripple Mode
Cripple Time: Amount of time unit is allow to run in cripple mode before shutting down. 0 - 120 Hrs 72 Hrs
HP Stop Time: This is the amount of time the HP shuts down to calculate failed sensor readings. 0 - 999 5 Min
Unit DA Limits: Unit Discharge Air Limits
Low Temp SP: Low Temperature Setpoint
0 - 100°F
(-17 - 38°C)
48ºF (8.9°C)
Hi Temp SP: High Temperature Setpoint
0 - 100°F
(-17 - 38°C)
85ºF (29.4°C)
Hi Dewpt SP: High Dewpoint Setpoint
0 - 100°F
(-17 - 38°C)
68ºF (20°C)
Limit Timer: 1 - 60 15 Min
↓ Menu Top Returns to the top of the menu
Control Display Description Range Factory Default
Press the Esc button to go back to Page 2
Page 3: (Only shown when CO2/VOC Alarm is selected and CO2 is equipped)
--CO2 Alarm--
CO2 Level: Current Sensor Level 0 - 9999
CO2 Setpoint: Sets the CO2 Alarm Setpoint 0 - 9999 800 ppm
Min. Runtime: Sets the Minimum Runtime 3 - 240 5 Min
Alm Off DB: Sets the CO2 Alarm Setpoint Dry Bulb 0 - 9999 50 ppm
Alarm Enabled: Alarm Enabled Yes / No Yes
Alm Delay: Sets the Alarm Delay Timer 10 - 900 30 Sec
Press the Esc button to go back to Page 2
8.0 Controls
(cont’d)
8.5 Controller Display Menus (cont’d)
6. SERVICE MENU (cont’d)
6E. Config Menu (cont’d)
