Reznor ZQYRA Unit Installation Manual - Manual (Page 51)

Form I-ZQYRA P/N 260414R5, Page 51
Pages 2&3: (Shown only when Hi OAT Lockout is selected)
--Alarm Help--
The outside air has exceeded the allowed high limit. Unit will
auto restart once the outside air is below high limit.
↓ Menu Top Returns to the top of the menu (Page 2)
Press the Esc button to go to page 1
Page 2: (Shown only when Dirty Filter Alarm is selected)
--Alarm Help--
The pressure limit for filter is above setpoint. The alarm is
monitored with a contact closure where a closure equals an
alarm condition.
↓ More More Items
Page 3: (Shown only when Dirty Filter Alarm is selected)
--Alarm Help--
1. Change filters.
2. Manually adjust pressure high limit setpoint at pressure
sensor.
↓ More More Items
Page 4:(Shown only when Dirty Filter Alarm is selected)
--Alarm Help--
3. See Paragraph 10.0 for more troubleshooting info.
↓ Menu Top Returns to the top of the menu (Page 2)
Press the Esc button to go to page 1
Page 2: (Shown only when Shutdown DI Alarm is selected)
--Alarm Help--
The manual shutdown DI is in alarm condition. The alarm is
monitored with a contact closure where an open contact equals
an open alarm condition.
↓ More More Items
Control Display Description
Page 3: (Shown only when Shutdown DI Alarm is selected)
--Alarm Help--
1. Correct manual alarm condition.
↓ More More Items
Page 4:(Shown only when Shutdown DI Alarm is selected)
--Alarm Help--
2. See Paragraph 10.0 for more troubleshooting info.
3. Contact technical support: 800-695-1901
↓ Menu Top Returns to the top of the menu (Page 2)
Press the Esc button to go to page 1
Pages 2&3: (Shown only when System Restart is selected)
--Alarm Help--
The system is in the automatic restart mode. The unit will restart
after one hour. See alarm history for latest alarms to occur. This
caused the restart. Resetting alarms or power cycling unit clears
restart mode.
↓ Menu Top Returns to the top of the menu (Page 2)
Press the Esc button to go to page 1
Pages 2,3,&4: (Shown only when BAS Shutdown Alarm is
selected)
--Alarm Help--
The BAS Shutdown command is in alarm condition. Unit will
not start until alarm is cleared. Unit can be overridden for a
set amount of time under BAS Shutdown config menu. BAS
Shutdown can also be disabled under the BAS Shutdown config
menu.
↓ Menu Top Returns to the top of the menu (Page 2)
Press the Esc button to go to page 1
Control Display Description
Page 1:
--User Display Help--
The menu below will help you navigate and use the user display.
Quickkey Shortcuts Opens the Quickkey Shortcuts Help
Buttons Opens the Button Help
↓ More More Items
Page 2: (Shown only when Quickkey Shortcuts is selected)
--Quickkey Shortcuts--
1. While on the Home / Summary page, holding "←" down for 5
seconds will take you to the Test Mode.
↓ More More Items
Page 3: (Shown only when Quickkey Shortcuts is selected)
--Quickkey Shortcuts--
2. While on the Home / Summary page, holding down the "←"
and “Prg" for 5 seconds will allow manual override of the unit
start/stop.
↓ More More Items
Page 4: (Shown only when Quickkey Shortcuts is selected)
--Quickkey Shortcuts--
3. While navigating the menu, if a ? is at the top right corner,
pressing the “Prg” button will take you to the built-in help menu.
↓ More More Items
Pages 5&6: (Shown only when Quickkey Shortcuts is selected)
--Quickkey Shortcuts--
4. While on the the alarm history screen, holding down the
“Alarm” and “Prg” will clear the Alarm History.
↓ Menu Top Returns to the top of the menu (Page 2)
Press the Esc button to go to page 1.
Page 2: (Shown only when Button is selected)
--Display Buttons--
1. Bell "Alarm" Button is used to move you to the active alarm
screen. Button will be illuminated when an alarm is present.
↓ More More Items
13. USER DISPLAY HELP MENU
To access a certain menu, use up or down arrow button to the desired selection, then press the enter button. Use the Esc button to
get back to the Main Menu.
Pages 3,4,&5: (Shown only when Button is selected)
--Display Buttons--
2. PRG Button has multiple functions. When on the Home or
Summary screens, the button moves you to the main menu.
When there is a “?” mark in the top right corner, the button
moves you to the built-in help screens. When on the manual test
screens, the button will reset the maximum test time back to 3
hours.
↓ More More Items
Pages 6&7: (Shown only when Button is selected)
--Display Buttons--
3. ESC Button is used to cancel a setpoint before accepting it.
The button also is used to move back to the previous menu.
↓ More More Items
Page 8: (Shown only when Button is selected)
--Display Buttons--
4. Up Arrow Button (↑) is used to move the cursor upwards
and change screens. It is also used to increase the value of a
setpoint.
↓ More More Items
Page 9: (Shown only when Button is selected)
--Display Buttons--
5. Enter Button (←) is used to select a line or setpoint indicated
by brackets [ ]. It also is used to accept the setpoint change.
↓ More More Items
Page 10,11,&12: (Shown only when Button is selected)
--Display Buttons--
6. Down Arrow Button (↓) is used to move the cursor downwards
and change screens. It is also used to decrease the value of a
setpoint.
↓ Menu Top Returns to the top of the menu (Page 2)
Press the Esc button to go to page 1
