Reznor ZQYRA Unit Installation Manual - Manual (Page 46)

Form I-ZQYRA P/N 260414R5, Page 46
Control Display Description Range Factory Default
↓ Returns to Page 1
Page 2: (Only shown when Occ Type is 5)
I want to control the unit using a CO2 Sensor with HOA.
↓ Configure Configure menu
Page 3: (Only shown when Occ Type is 5)
--Occupancy Type 5--
Occ Type: Current Occupancy Type 5
CN Option: Current CN Option CN7B
Sensor: Current Sensor Type CO2
HOA Input: Hand-Off-Auto Status
CO2 Level: Current CO2 Level Reading
CO2 Setpt: Sets the CO2 Setpoint 0 - 9999 800ppm
Off Diff: Sets the CO2 Setpoint Offset Differential 0 - 9999 50ppm
Min Runtime: Sets the Minimum Runtime 3 - 240 5 Min
Alarm: Sets the alarm Disable / Enable Enable
↓ Returns to Page 1
Page 2: (Only shown when Occ Type is 6)
I want to control the unit using a VOC Sensor with HOA.
↓ Configure Configure menu
Page 3: (Only shown when Occ Type is 6)
--Occupancy Type 6--
Occ Type: Current Occupancy Type 6
CN Option: Current CN Option CN7C
Sensor: Current Sensor Type VOC
HOA Input: Hand-Off-Auto Status
VOC Level: Current VOC Lavel Reading
VOC Setpt: Sets the VOC Setpoint 0 - 100 60%
Off Diff: Sets the VOC Setpoint Offset Differential 0 - 100 15%
Min Runtime: Sets the Minimum Runtime 3 - 240 5 Min
Alarm: Sets the alarm Disable / Enable Enable
↓ Returns to Page 1
Page 2: (Only shown when Occ Type is 7)
I want to control the unit using the DI but allow VOC/CO2 to turn unit on above setpoint.
↓ Configure Configure menu
Page 3: (Only shown when Occ Type is 7)
--Occupancy Type 7--
Occ Type: Current Occupancy Type 7
CN Option: Current CN Option CN5
Sensor: Current Sensor Type CO2
Set Sensor Type first!
↓ More More Menu Items
Page 4: (Only shown when Occ Type is 7)
--Occupancy Type 7--
Occ Type: Current Occupancy Type 7
CN Option: Current CN Option CN5
Sensor: Sets the Sensor Type CO2 / VOC CO2
Set Sensor Type first!
↓ More More Menu Items
Page 5: (Only shown when Occ Type is 7 and Sensor is CO2)
--Occupancy Type 7--
Sensor: Current Sensor Type CO2
CO2 Level: Current CO2 Level Reading
CO2 Setpt: Sets the CO2 Setpoint 0 - 9999 800ppm
Off Diff: Sets the CO2 Setpoint Offset Differential 0 - 9999 50ppm
Min Runtime: Sets the Minimum Runtime 3 - 240 5 Min
Alarm: Sets the alarm Disable / Enable Enable
↓ Returns to Page 1
Page 5: (Only shown when Occ Type is 7 and Sensor is VOC)
--Occupancy Type 7--
Sensor: Current Sensor Type CO2
VOC Level: Current VOC Level Reading
VOC Setpt: Sets the VOC Setpoint 0 - 100 60%
Off Diff: Sets the VOC Setpoint Offset Differential 0 - 100 15%
Min Runtime: Sets the Minimum Runtime 3 - 240 5 Min
Alarm: Sets the alarm Disable / Enable Enable
↓ Returns to Page 1
Page 2: (Only shown when Occ Type is 8)
I want to control the unit using a schedule and allow VOC/CO2 to turn unit on above setpoint.
↓ Configure Configure menu
Page 3: (Only shown when Occ Type is 8)
--Occupancy Type 8--
8.0 Controls
(cont’d)
8.5 Controller Display Menus (cont’d)
7. OCCUPANCY CONFIG MENU (cont’d)
