Form I-ZQYRA P/N 260414R5, Page 40
Control Display Description Range Factory Default
Runtimes: Component Run Hours
Reset To Zero?: Reset Component Run Time to Zero No/Yes No
Alarm Enabled?: Enables Component Run Time Alarm No/Yes No
Setpoint: Component Run Time Alarm Setpoint
Press the Esc button to go back to the Page 1
6D. System Menu
Use the up or down arrow button to the desire selection, then press the enter button to open or change. Use the up or down arrow
button to change the value and press the enter button. Use the Esc button to get back to the Service Menu
.
Control Display Description Factory Default
Page 1:
- - System Menu - -
Clockset Opens the System Clock Set Menu
Support PH # Opens the Change Support Phone Number Menu
BAS Config Opens the BAS Config Menu
Controller Opens the Controller Menu
↓ Menu Top Returns to the top of the menu
Page 2: (Only shown when Clockset is selected)
-- Clockset Menu --
Week Day: Day of the week Monday/Tuesday/Wednesday/Thursday/Friday/Saturday/Sunday
Month: Month 01-12
Day: Day 01-31
Year: Year 00-99
Hour: Hour 00-23
Minute: Minute 00-59
Press the Esc button to go back to the Page 1
Page 2: (Only shown when Support PH# is selected)
-- Support Phone Menu --
Area Code: Telephone Area Code 000-999
Prefix: Telephone Prefix Number (the first 3 numbers) 000-999
Suffix: Telephone Suffix Number (the last 4 numbers) 0000-9999
Press the Esc button to go back to the Page 1
Page 2: (Only shown when BAS Config is selected)
-- BMS Config Menu --
BMS PORT 1
Protocol: Sets current protocol
N/A / CAREL / MODEM / MODBUS / PCOLOAD / BACnet MSTP /
BACnet IP/Eth / LON / MODBUS EXT
BACnet PlugIn?: Sets the BACnet PlugIn command (Only shown when
Protocol is BACnet MSTP or BACnet IP/Eth)
Yes / No
DHCP?: Cuurent DHCP Command (Only shown when
Protocol is BACnet ID/Eth)
↓ Next Menu
Page 3: (Only shown when Protocol is N/A)
--BMS Config Menu--
BMS PORT 1
Address: Sets Controller Address. 0 - 999
Baud Rate: Sets the Baud Rate 1200 / 2400 / 4800 / 9600 / 19200
Address: Sets the Address2 1 - 207
↓ Return to the top of the menu (Page 2)
Page 3: (Only shown when Protocol is CAREL)
--BMS Config Menu--
BMS PORT 1
Address: Sets Controller Address. 0 - 999
Baud Rate: Sets the Baud Rate 1200 / 2400 / 4800 / 9600 / 19200
Address: Sets the Address2 1 - 207
↓ Return to the top of the menu (Page 2)
Page 3: (Only shown when Protocol is MODEM)
-- BMS Config Menu --
BMS PORT 1
Address: Sets Controller Address. 0 - 999
Baud Rate: Sets the Baud Rate 1200 / 2400 / 4800 / 9600 / 19200
Address: Sets the Address2 1 - 207
↓ Return to the top of the menu (Page 2)
Page 3: (Only shown when Protocol is MODBUS)
-- BMS Config Menu --
BMS PORT 1
Address: Sets Controller Address. 0 - 999
Baud Rate: Sets the Baud Rate 1200 / 2400 / 4800 / 9600 / 19200
Address: Sets the Address2 1 - 207
↓ Return to the top of the menu (Page 2)
8.0 Controls
(cont’d)
8.5 Controller Display Menus (cont’d)
6. SERVICE MENU (cont’d)
6 C. Run Times Menu (cont’d)
