Control Display Description
HP Menu Opens HP Menu
PreHeat Menu Opens PreHeat Menu (Shown only when Pre-Heat is enabled.)
Alarm History Opens Alarm History Menu
Alarm Help Opens Alarm Help Menu
User Display Help Opens User Display Help Menu
Login Opens User Login
4. QUICK SETPOINTS MENUS
There are 4 different menus dependent to Temp Cntrl. Temp Cntrl (temperature control) is part of unit configuration. To access/
change Temp Cntrl, go to Service Menu / Config / Edit Equip Config.
To change the value of a setpoint, use the up or down arrow button to find the desired setpoint. Press the enter button, then the up
arrow button to increase or the down arrow button to decrease the setpoint. When you get the desired value, press the enter button.
Use the up or down arrow button again to move to other setpoints or press the Esc button to get out of the Quick Setpoints Menu
Control Display Description Range Factory Default
- - Quick Setpoints Menu- -
Page 1: (Used when Temp Cntrl set to “Dp”) (See alternates below)
DpCngOvrLt: Wheel Dewpoint Changeover Limit - This is the point at which the discharge air temperature
swaps between DatSpHiDp setpoint and the DatSpLoDp setpoint.
52 - 65°F
(11 - 18°C)
59°F (15°C)
DatSpHiDp: Discharge Air Temperature Setpoint with High Dewpoint - This setpoint is used when the ER
Wheel Dewpoint is greater than the DpCngOvrLt setpoint.
52 - 75°F
(11 - 24°C)
58°F (14°C)
DatSpLoDp: Discharge Air Temperature Setpoint with Low Dewpoint - This setpoint is used when the ER
Wheel Dewpoint is lower than the DpCngOvrLt setpoint.
52 - 75°F
(11 - 24°C)
70°F (21°C)
ActDatSetpt: Active Unit Discharge Air Temperature Setpoint
Page 1 Alternate: (Used when Temp Cntrl set to “HtgClgOa”):
DpCngOvrLt: Wheel Dewpoint Changeover Limit - This is the point at which the discharge air temperature
swaps between DatSpHiDp setpoint and the DatSpLoDp setpoint.
52 - 65°F
(11 - 18°C)
59°F (15°C)
DatSpHiDp: Discharge Air Temperature Setpoint with High Dewpoint - This setpoint is used when the ER
Wheel Dewpoint is greater than the DpCngOvrLt setpoint.
52 - 75°F
(11 - 24°C)
58°F (14°C)
*DatHtgSpLoDp:
Discharge Air Temperature Heating Setpoint with Low Dewpoint - This setpoint is used
when the ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the outside air
temperature is less than the HtgClgCngOvr setpoint.
52 - 75°F
(11 - 24°C)
70°F (21°C)
*DatClgSpLoDp:
Discharge Air Temperature Cooling Setpoint with Low Dewpoint - This setpoint is used when
the ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and outside air temperature
is greater than the HtgClgCngOvr setpoint.
52 - 75°F
(11 - 24°C)
60°F (15.5°C)
OaCngOvr: Heating/Cooling Discharge Air Temperature Changeover Setpoint - This is the point at which
the DAT setpoint swaps between the DatHtgSpLoDp and DatClgSpLoDp setpoints.
52 - 80°F
(11 - 27°C)
65°F (18°C)
OaCngOvrDb: Heating/Cooling Discharge Air Temperature Changeover Deadband Setpoint - This is the
degrees the OAT must drop once the system swaps to the DatClgSpLoDp setpoint.
1 -10° 2°
ActDatSetpt: Active Unit Discharge Air Temperature Setpoint
Page 1 Alternate: (Used when Temp Cntrl set to “HtgClgSpc”)
DpCngOvrLt: Wheel Dewpoint Changeover Limit - This is the point at which the Discharge Air Temperature
swaps between DatSpHiDp setpoint and the DatSpLoDp setpoint.
52 - 65°F
(11 - 18°C)
59°F (15°C)
DatSpHiDp: Discharge Air Temperature Setpoint with High Dewpoint - This setpoint is used when the ER
Wheel Dewpoint is greater than the DpCngOvrLt setpoint.
52 - 75°F
(11 - 24°C)
58°F (14°C)
*DatHtgSpLoDp:
Discharge Air Temperature Heating Setpoint with Low Dewpoint - This setpoint is used when
the ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the Zone temperature is
less than the HtgClgCngOvr setpoint.
52 - 75°F
(11 - 24°C)
70°F
(21°C)
*DatClgSpLoDp:
Discharge Air Temperature Cooling Setpoint with Low Dewpoint - This setpoint is used when
the ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the zone temperature is
greater than the HtgClgCngOvr setpoint.
52 - 75°F
(11 - 24°C)
60°F
(15.5°C)
ZnCngOvr: Heating/Cooling Discharge Air Temperature Changeover Setpoint - This is the point at which
the DAT setpoint swaps between the DatHtgSpLoDp and DatClgSpLoDp setpoints.
52 - 80°F
(11 - 27°C)
65°F
(18°C)
ZnCngOvrDb: Heating/Cooling Discharge Air Temperature Changeover Deadband Setpoint - This is the
degrees the Zone Temp must drop once system swaps to the DatClgSpLoDp setpoint.
1 - 10° 2°
ActDatSetpt: Active Unit Discharge Air Temperature Setpoint - -
Page 1 Alternate: (Used when Temp Cntrl set to “OaReset”)
DpCngOvrLt: Wheel Dewpoint Changeover Limit - This is the point at which the Discharge Air Temp swaps
between the DatSpHiDp setpoint and the DatSpLoDp setpoint.
52 - 65°F
(11 - 18°C)
59°F (15°C)
DatSpHiDp: Discharge Air Temperature Setpoint with High Dewpoint - This setpoint is used when the ER
Wheel Dewpoint is greater than the DpCngOvrLt setpoint.
52 - 75°F
(11 - 24°C)
58°F (14°C)
OatLoSpLoDp:
Outside Air Temperature Low Setpoint with Low Dewpoint - This is the Outside Air Low
Limit Reset setpoint. When the OA Temp is equal to this setpoint, the Unit Discharge air
temperature setpoint equals DatHiSpLoDp.
0 - 80°F
(-13 - 27°C)
50°F (10°C)
OatHiSpLoDp:
Outside Air Temperature High Setpoint with Low Dewpoint - This setpoint is the Outside Air
High Limit Reset setpoint. When the outside air temperature is equal to this setpoint, the unit
discharge air temperature setpoint equals DatLoSpLoDp.
0 - 80°F
(-18 - 27°C)
70°F (21°C)
*DatHiSpLoDp:
Discharge Air Temperature High Setpoint with Low Dewpoint - This setpoint is used when the
ER Wheel Dewpoint is lower than the DpCngOvrLt setpoint and the outside air temperature
is equal to the OatLoSpLoDp. The DAT setpoint is reset linearly between the DatHiSpLoDp
and DatLoSpLoDp setpoints.
52 - 75°F
(11 - 24°C)
70°F (21°C)
8.0 Controls
(cont’d)
8.5 Controller Display Menus (cont’d)
3. MAIN MENUS (cont’d)
