Haltech E8 User Manual
Page 74
Haltech E11/E8 Instruction Manual
•
VANOS Ref Signal
- For control of BMWs VANOS system two signal inputs are required. The
VANOS ref signal reads the fixed 8 pulse signal on the camshaft.
•
VANOS Inlet Cam Signal
- the VANOS Inlet Cam digital timed input can be connected to read the
variable (moving) 8 pulse signal on the camshaft of a VANOS equipt engine.
•
Intercooler Spray Input –
When using intercooler spray advanced this input is required to be
enabled before the intercooler spray will activate.
Data Logging - See Datlogging section for Details.
Page: 74
Copyright © Haltech 2008
