Haltech E11/E8 Instruction Manual
Motronic 60-2 Distributor
Waste Spark These are typically magnetic pickups that are
located on the crank. This style of pickup looks
as if it should have 60 evenly spaced teeth
however there are 2 teeth missing leaving only
58 teeth with a gap the width of 2 teeth at one
location.
These are commonly found on European cars
such as Audi, BMW, Porsche and Volkswagon.
Motronic 36-1 Multipoint
Batch
Semi-
Sequential Distributor
Waste Spark These are commonly found on Ford engines.
Typically magnetic pickups that are located on
the crank. This style of pickup looks as if it
should have 36 evenly spaced teeth however
there is 1 tooth missing leaving only 35 teeth
with a gap the width of 1 tooth at one location.
Motronic 36-2 Multipoint
Batch
Semi-
Sequential Distributor
Waste Spark These are sometimes found on Toyota engines.
Typically magnetic pickups that are located on
the crank. This style of pickup looks as if it
should have 36 evenly spaced teeth however
there are 2 teeth missing leaving only 34 teeth
with a gap the width of 2 teeth at one location.
Motronic 60-2 +
Cam home Multipoint
Batch
Semi-
Sequential
Sequential Distributor
Waste Spark
Direct Fire With the addition of the Home signal on the
cam, this trigger enables the support of full
sequential injection and direct fire multi-coil
ignition.
These are commonly found on European cars
such as Audi, BMW, Porsche and Volkswagon.
Motronic 36-1 +
Cam home Multipoint
Batch
Semi-
Sequential
Sequential Distributor
Waste Spark
Direct Fire With the addition of the Home signal on the
cam, this trigger enables the support of full
sequential injection and direct fire multi-coil
ignition.
These are commonly found on Ford engines.
Motronic 36-2 +
Cam home Multipoint
Batch
Semi-
Sequential
Sequential Distributor
Waste Spark
Direct Fire With the addition of the Home signal on the
cam, this trigger enables the support of full
sequential injection and direct fire multi-coil
ignition.
These are sometimes found on Toyota engines.
Subaru Multipoint
Batch
Semi-
sequential
Sequential Distributor
Twin
Distributor
Waste Spark
Direct fire
coils For Subaru 4 cylinder EJ series engines.
Distributor
