Optional Idle Air Control Motor.
Optional Ignition Coils - Available as Single and dual.
Optional Ignition Igniter with Dwell Control - Available as single and dual igniters.
Optional Ignition Igniter without Dwell Control - Available as single, dual and triple igniters.
Optional Mixture / Ignition / Boost Trim Module - Provides ±12½%, ±25% or ±50% injection time
adjustment for fast tuning. Provides -10° to +10° ignition advance adjustment for fast tuning Provides 0 -
100% boost trim adjustment.
Output Channel Electrical Characteristics
The following table describes the electrical characteristics of the output channels when used for Auxiliary
devices that are assumed to be small solenoids, automotive relays, or constant loads.
The complex drive characteristics for driving injectors are not described here.
Auxiliary Channel Output Type
IGN 1 12V 5mA low current drive output / 1A sink current to GND
IGN 2 12V 5mA low current drive output / 1A sink current to GND
IGN 3 12V 5mA low current drive output / 1A sink current to GND
IGN 4 12V 5mA low current drive output / 1A sink current to GND
IGN 5 / INJ 8 12V 5mA low current drive output / 1A sink current to GND
IGN 6 / INJ 7 12V 5mA low current drive output / 1A sink current to GND
INJ 6 1A sink current to GND
INJ 5 1A sink current to GND
INJ 4 1A sink current to GND
INJ 3 1A sink current to GND
INJ 2 1A sink current to GND
INJ 1 1A sink current to GND
Aux 1 1A sink current to GND
Aux 2 1A sink current to GND
PWM1 12V/8V/5V 1mA current drive output / 1A sink current to GND
PWM2 1A sink current to GND
PWM3 1A sink current to GND
PWM4 1A sink current to GND
Input Channel Electrical Characteristics
Input Channel Input Type
Aux In 1 0 – 12V (Input is active when input is GND)
Timed Input 1 0 – 12V
Timed Input 2 0 – 12V
Timed Input 3 0 – 12V
Input Channel Input Type
Copyright © Haltech 2008 Page: 165
