Haltech E11/E8 Instruction Manual

Typical Engine Configurations

Table applicable for E11, E8 May Have Additional Limitations Based on the Number of Drivers on Board.

3 Cylinder Engines

Output
Pin

3 Cyl Sequential
Distributor

3 Cylinder Sequential
Direct Fire

Home

Home / Nissan Large
Tooth

Trigger

Trigger / Nissan Fine
Tooth

IGN 1

Ignition 1

IGN 2

Dig Out/PWM/Aux
Injector

IGN 3

Dig Out/PWM/Aux
Injector

IGN 4

Dig Out/PWM/Aux
Injector

IGN 5 /
INJ 8

Dig Out/PWM/Aux
Injector

IGN 6
INJ 7

Dig Out/PWM/Aux
Injector

INJ 6

Dig Out/PWM/Aux
Injector

INJ 5

Dig Out/PWM/Aux
Injector

INJ 4

Dig Out/PWM/Aux
Injector

INJ 3

Injector 3

INJ 2

Injector 2

INJ 1

Injector 1

Aux 1

Dig Out/PWM/Aux
Injector

Aux 2

Dig Out/PWM/Aux
Injector

PWM1

Discrete Out/PWM Out

PWM2

Discrete Out/PWM Out

PWM3

Discrete Out/PWM Out

PWM4

Discrete Out/PWM Out

Waste spark not
applicable

Home / Nissan Large
Tooth

Trigger / Nissan Fine
Tooth

Ignition 1

Ignition 2

Ignition 3

Dig Out/PWM/Aux
Injector

Dig Out/PWM/Aux
Injector

Dig Out/PWM/Aux
Injector

Dig Out/PWM/Aux
Injector

Dig Out/PWM/Aux
Injector

Dig Out/PWM/Aux
Injector

Injector 3

Injector 2

Injector 1

Dig Out/PWM/Aux
Injector

Dig Out/PWM/Aux
Injector

Discrete Out/PWM Out

Discrete Out/PWM Out

Discrete Out/PWM Out

Discrete Out/PWM Out
