Haltech E11/E8 Instruction Manual
3 Rotor Engines
Output
Pin 3 Rotor Sequential
Direct Fire 3 Rotor Waste Spark 3 Rotor Sequential
Distributor
Home Home Illegal Combination Home
Trigger Trigger Trigger
IGN 1 Ignition 1 Leading Ignition 1 Leading
IGN 2 Ignition 2 Leading Ignition 2 Leading
IGN 3 Ignition 3 Leading Dig Out/PWM/Aux
Injector
IGN 4 Ignition 1 Trailing Dig Out/PWM/Aux
Injector
IGN 5 /
INJ 8 Ignition 2 Trailing Dig Out/PWM/Aux
Injector
IGN 6
INJ 7 Ignition 3 Trailing Dig Out/PWM/Aux
Injector
INJ 6 Injector 3 Secondary Injector 3 Secondary
INJ 5 Injector 2 Secondary Injector 2 Secondary
INJ 4 Injector 1 Secondary Injector 1 Secondary
INJ 3 Injector 3 Primary Injector 3 Primary
INJ 2 Injector 2 Primary Injector 2 Primary
INJ 1 Injector 1 Primary Injector 1 Primary
Aux 1 Dig Out/PWM/Aux
Injector Dig Out/PWM/Aux
Injector
Aux 2 Dig Out/PWM/Aux
Injector Dig Out/PWM/Aux
Injector
PWM1 Discrete Out/PWM Out Discrete Out/PWM Out
PWM2 Discrete Out/PWM Out Discrete Out/PWM Out
PWM3 Discrete Out/PWM Out Discrete Out/PWM Out
PWM4 Discrete Out/PWM Out Discrete Out/PWM Out
