Haltech E11/E8 Instruction Manual
• Multipoint mode - Injection is the most basic form of injection that fires all injectors
simultaneously. This mode of injection does not require any home or reference signal to
operate. The angle of injection is not defined, and the injection angle map is not used. The
frequency of injection is defined by the Ignition Divide By parameter.
For Piston Engines
Trigger Injection Mode
Standard Trigger Full Cycle, with home on the CAM
24 +1 Multi-Tooth trigger (Honda, Toyota)
Nissan Trigger
Motronic with home signal on the CAM
Subaru
Subaru MY01 Sequential
Standard Trigger Full Cycle, with home on the CAM
Standard Trigger Half Cycle, with home on the crank
24 +1 Multi-Tooth trigger (Honda, Toyota)
Nissan Trigger
Motronic
Subaru
Subaru MY01 Semi-Sequential
Standard Trigger
24 +1 Multi-Tooth trigger (Honda, Toyota)
Nissan Trigger
Subaru
Subaru MY01 Batch
All triggers Multipoint
For Rotary Engines
Trigger Injection Mode
Standard Trigger with crank home
24 +2 Multi-Tooth trigger Sequential
Standard Trigger with no home Multipoint
• Ignition Divide By - This parameter is only used in batch and multipoint injection modes. The
value of ignition divide by will determine the number of injections per engine cycle. E.g. If the
engine is a 4 stroke 4 cylinder, then an ignition divide by of 2 will enable 1 injection for every 2
ignition events. This is the equivalent of one injection per crank rev. If you are unsure what to set
this to, then leave the value set to the default of half the number of cylinders.
