Haltech E11/E8 Instruction Manual
a list of sub windows that you can select from. When you select one of these windows from this menu, the
program will bring it to the front of all the other windows.
To toggle through all the windows with keystrokes, you can use Ctrl-Tab to flip through all your open
windows much like Alt-Tab is used for the main windows. Likewise Ctrl-F4 will close any sub window that
you have open.
Gauge and Engine Data Pages
Gauge Page
The gauge page displays the most typical engine running information to allow you to see the general
status of your engine. You can open this page by selecting it through the Page menu or by pressing ‘Ctrl-
G’.
Figure 118 - Guage Page
Visual Features
The engine RPM gauge can be setup to show a Redline to suit the engine being tuned. The needle and
the numeric display will turn red when this RPM is reached or exceeded. The scale will show the Redline
at the nearest 1000 RPM.
The ‘Dial Properties’ button allows the Redline of the Engine RPM gauge to be altered to suit.
