89
85%
Model 1
Mixing Rate
Swash Detail Swash(AFR)
PIT to ELE
AIL to PIT
ELE to AIL
ELE to PIT
100% 100%
100% 100%
100% 100%
50% 50%
50% 50%
PIT to AIL
Mixing
Linkage Compensation
Function Dir.
Aileron
Elevator
Speed Compensation
0% 0%
0% 0%
0%
Low Pitch
+
+
●Return to Linkage Menu
●To Swash
AFR screen
85%
Model 1
Neutral Point Swash AFR
Aileron
Elevator
H 100%
50% 50%
0% L
Low Pitch
+50%
Enter
Pitch
Swash Swash Detail
High Pitch
+50%
+50%
●Return to Linkage Menu
●Touch the [Swash] button in the Linkage Menu to
call the setup screen shown below.
Swash Swash operation linkage correction function
(This swash setup screen does not appear for swash type H-1.)
Neutral Point
On your linkages, if the servo horn deviates from
perpendicular at neutral, the linkage compensation
functions may not work effectively. This neutral
point setting reads the linkage compensation neutral
position. However, this adjustment only changes
the reference point of the compensation function
on the swash details screen and does not affect the
neutral position of other functions.
*Before using the compensation function, set the neutral
point.
Swash AFR
The swash AFR function adjusts (increases/
decreases/reverse) the rate (travel) of the aileron,
elevator, and pitch functions.
Mixing Rate
(Normally, the default value is used.)
This mixing rate is used for minor correction
to the swash plate so that it moves in the correct
direction for aileron, elevator, and pitch operation.
Compensation mixing is shown below.
*PIT->AIL/PIT->ELE/AIL->PIT/ELE->AIL/ELE->PIT
*Use the corresponding compensation mixing and adjust so
that the swash plate moves in the correct direction
Linkage Compensation
This compensation mixing is used to adjust for
interference when the ailerons or elevators are
operated when the throttle stick was in the low or
high position.
Speed Compensation
This speed compensation function make
adjustments for interference when the travel of
each servo is different due to swash plate operation.
For HR-3, it compensates the speed by dropping
the operating speed of the aileron and pitch servos
during elevator operation.
●To Swash
Details screen
