133
85%
Model 1 Condition 1
Speed
Motor Off +0
Group
ON Switch
INH ACT/INH ACT/INH ON
OFF
One time mode
+0 Speed 1 to 2
Speed1
Speed2
INH
Gr.
Motor
INH
0 0
0 0
In Out
●Return to Model Menu
Motor [Corresponding model type]: EP glider/Airplane, general
This function lets you set the operation speed
when the motor of a F5B or other EP glider is
started by switch. The operation speed can be set
in 2 ranges of slow speed flight and high speed
flight (Speed 1/Speed 2). This function can also be
operated as a safety function by setting 2 switches.
● The In side and Out side operating speeds can
be adjusted independently in 2 ranges (Speed
1/Speed 2).
● The boundary between the 2 ranges can be set.
(From Speed 1 to Speed 2)
● The set operation speed operation can be
activated at initial operation only. (1 time
operation) However, operation can be repeated
● Touch the [Motor] button in the Model Menu
to call the setup screen shown below.
● Move the cursor by set
switch or VR.
by setting the switch to OFF before operation is
finished. When you want to reset 1 time operation,
set the ACT button to [INH] and then reset it to
[ON].
● The motor is controlled by SW-G[Mode1]SW-
E[Mode2]. (Initial setting) When changing the
switch or stick which controls the motor, first
change Function of the Linkage Menu.
Note: When using this function, always check initial
operation with the propeller removed.
Note: A warning message appears when this mix is on at
the time of power up.
● Operation
Touch the button and set the function to ON.
● When you want to set the "One time mode",
touch the button and set the mode to [ON].
● Speed 1 to 2
The Speed 1 and Speed 2 region boundary
can be changed,
● Operation speed adjustment
The speed when Speed 1 and Speed 2 are
ON (In) and OFF (Out) can be adjusted.
● Operation
Touch the button and set the function to
ON.
● Group/single mode switching (Gr./Sngl)
● Switch
A switch that turns the function itself
ON/OFF can be selected.
● Motor off
[Yes] and [No] are displayed by touching
the Motor Off button when [SW-G(Mode1)]
[SW-E(Mode2)] (Initial setting) is in the motor
OFF position. When [Yes] is touched, the
direction of the motor switch is memorized.
The screen graph display ON direction also
changes.
Notes
● First decide the motor OFF point, and then set the speed. When you want to
reset the motor OFF point, also reset the speed.
● We recommend that Motor OFF be set in combination with F/S.
● Set the basic operation direction with the Reverse function to match the
amp used.
● Always set the Motor OFF position.
