120
AIL 3
(Chip Aileron)
AIL 4
(Chip Aileron)
AIL1
(Main Aileron)
AIL 2
(Main Aileron)
FLP 2
(Camber Flap) FLP 1
(Camber Flap)
ELEVATOR ELEVATOR 2
at V-TAIL
ELEVATOR ELEVATOR 2
(at AILEVATOR)
FLP 3
(Brake Flap)
FLP 4
(Brake Flap)
Setting method
● Touch the "INH" button and set the function to ACT
(ON).
● When setting a switch, touch the [ON] button to
call the screen, and then select the
switch and set its ON direction. (Always ON at
"ON" setting)
● When setting a condition delay, touch the
Condition Delay button and set the delay with the
adjustment buttons which appear on the screen.
The VR operation mode can also be set.
● Camber AFR(D/R) screen call
Touch the Camber AFR button to call the setup
screen.
(Curve/rate setup screen)
● The curve and rate are adjusted by calling the
aileron, flap, and elevator curve/rate screens.
The rate and curve of each servo can be set by
calling each screen. The servo speed can also be
adjusted.
