40
Trainer Trainer system set up and use.
T18MZ trainer system makes it possible for the
instructor to chose which channels and operation
modes that can be used in the students transmitter.
The function and rate of each channel can be
set, the training method can also be matched to
the student's skill level. Two transmitters must be
connected by an optional Trainer Cord, and the
Instructors’ transmitter should be programmed for
trainer operation, as described below.
When the Instructor activates the trainer switch,
the student has control of the aircraft (if MIX/
FUNC/NORM mode is turned on, the Instructor
can make corrections while the student has control).
When the switch is released the Instructor regains
control. This is very useful if the student gets the
aircraft into an undesirable situation.
● Setting data are stored to model data.
● Student rate can be adjusted at MIX/FUNC/
NORM mode.
● Activated student channels can be selected
by switches.
NOTE: This trainer system can be used in the
following manner;
1. In the T18MZ (including FX-40, T12Z and
T12FG) transmitter and a conventional
transmitter, if the channel order is different.
It is necessary to match the channel order
in the Linkage Menu when connecting it
with other than a T18MZ.
2. Be sure that all channels work correctly in
both transmitters before flying.
Corresponding types of transmitters and trainer mode settings:
Types of transmitters
Instructor's transmitter settings Student's transmitter settings
Freq. setting Trainer setting Freq. setting Trainer setting Trainer Cords
Instructor Student Mod. mode CH mode Mod. mode CH mode Mod. mode
T18MZ T18MZ Arbitrary 16CH Arbitrary 16CH -
12FG/9C Trainer
Cords
T18MZ
T14MZ, FX-40,
T12Z, T12FG,
FX-30
Arbitrary 12CH
PCM-G3
2.4G
12CH PPM
T18MZ T8FG, FX-20 Arbitrary
12CH FASST-MLT2
- -
8CH FASST-MULT
T18MZ
T10C, T9C,
T7C,T6EX,
T4EX
Arbitrary 8CH PPM - - 12FG Trainer Cords
T18MZ T10CG,T7CG Arbitrary 8CH Arbitrary - - 12FG Trainer Cords
T18MZ T8J,T6J Arbitrary 8CH Arbitrary - -
12FG/9C Trainer
Cords
T14MZ, FX-40,
T12Z, T12FG,
FX-30
T18MZ Arbitrary 12CH Arbitrary 12CH -
T8FG, FX-20 T18MZ Arbitrary 12CH Arbitrary 12CH -
T10C, T10CG,
T9C, T7C,
T7CG,T8J
T18MZ Arbitrary - Arbitrary 8CH -
● Touch the [Trainer] button in the System Menu to
call the setup screen. The setup screen for the
Teacher/Student mode is shown below.
85%
Trainer
Student
INH ACT/INH
8CH Channel
Teacher/Student
Model 1
Student mode
1. Set "Teacher/ Student" button to "Student".
2. Change "ACT/INH" button from "INH" to "OFF"
or "ON".
3. Set the CH mode to "16CH/12CH" or "8CH",
see the above chart for the trainer mode
●Return to System Menu
settings.
Note: In "student mode", only the teacher
side can turn on and off the power of the
student's transmitter. Keep the power switch
always at off position.
