FUNCTIONS OF LINKAGE MENU
System Menu
--Condition Hold
Linkage Menu Model Menu Cond.Hold
Model 1 Normal
85%
Linkage Menu
Model Select Model Type Picture
System Type Function Sub-Trim
Fail Safe Throttle Cut
Timer Swash Ring Swash
Sound
Servo Monitor
Servo Reverse
Idle Down
INH
End Point(ATV)
1/2
The Linkage Menu has all of the functions you
will need to perform model addition, model type
selection, frequency setting, end point setting, and
other model basic settings.
●Return to Home screen
● When you touch the Linkage Menu button on the Home
screen, the menu shown below is called up. Touch the
button of the function you want to set.
The functions which can be selected depend on
which model type you are using. A typical menu
screen is shown below.
Linkage Menu functions table
[Servo Monitor]: Displays the servo test and operation position
[Model Select]: Model addition, call, deletion, copy, model name setting
[Model Type]: Model type, wing type, switch type, etc. selection
[Picture]: Picture selection and setting for each model
[Sound]: Sound recording and playback
[System Type]: System selection, receiver link, telemetry.
[Function]: Channel assignment of each function can be changed
[Sub-Trim]: Adjusts the neutral position of each servo
[Servo Reverse]: Servo direction reversal
[Fail Safe]: Fail safe function and battery fail safe function setting
[End Point (ATV)]: Servo basic rudder adjustment and limit setting
[Throttle Cut]: Stops the engine safely and easily (airplane and helicopter only)
[Idle Down]: Lowers the idle speed of the engine (airplane and helicopter only)
[Swash Ring]: Limits the swash travel within a fixed range to prevent linkage damage (helicopter only)
[Swash]: Swash AFR and linkage correction function (helicopter only)
[Timer]: Timer setting and lap time display
[Dial Monitor]: Dial, slider, and digital trim position display and setting.
[Function Name]: Function Name can be changed
[Telemetry]: Displays various data sent from the receiver.
[Sensor]: Various telemetry sensors setting
[Warning]: Warning sound and vibration setting.
[Data Reset]: Model memory data reset (by various item)
Condition Hold function ON/OFF button
For a detailed description, see p.101(Condition Hold function).
