129
85%
INH GY AVCS AVCS
ACT Type
OFF
Switch
Rate1
Model 1 Gyro
0%
Gyro Gyro2 Gyro3
0% AVCS 0%
Condition 1
Gr.
INH GY AVCS AVCS
ACT Type
OFF
Switch
Rate2 0%
Gyro Gyro2 Gyro3
0% AVCS 0%
Gr.
INH GY AVCS AVCS
ACT Type
OFF
Switch
Rate3 0%
Gyro Gyro2 Gyro3
0% AVCS 0%
Gr.
Gyro Rate
●Return to Model Menu
Gyro [Corresponding model type]: Airplane/glider, general
This function is used when a gyro is used to
stabilize the fuselage attitude. The sensitivity and
operation mode (Normal mode/GYmode) can be
switched with a switch.
● Three rates (Rate 1/Rate 2/Rate 3) can be
switched.
● Up to 3 axes (Gyro/Gyro 2/Gyro 3) can be
simultaneously controlled.
*Initial setting does not assign a sensitivity channel. Use the
● Touch the [Gyro] button in the Model Menu
to call the setup screen shown below.
Function menu of the Linkage Menu to assign the sensitivity
channel (Gyro/Gyro2/Gyro3) used to a vacant channel
beforehand.
Set [ACT] and [Trim] other than Function to [NULL].
● The operation mode (AVCS/NOR) and sensitivity of
the 3 axes Gyro/Gyro2/Gyro3 can be set.
● Group/single mode switching
(Gr./Sngl)
(For more information, see the description
at the back of this manual.)
● Three rates (Rate 1/Rate 2/Rate 3) can be used.
● Touch the ACT button of the rate to be used, and set the function to
ACT ([ON] or [OFF]).
● When a Futaba gyro is used, when [GY] type is s elected, the sensitivity
set value is directly read in both the AVCS and NOR modes.
● When setting a switch, touch the switch button to call the
screen, and then select the switch and set its ON direction.
