Throttle Limiter
This function limits the high range of the
throttle movement by any slider or trimmer. The
adjustment range of the high and low end can be
set.
● Return to Model Menu
● Touch the [Throttle Limiter] button of the
Model Menu to call the setup screen shown
below.
Setting method
●Activate the mixing and select the on/off switch.
●Select the control for adjustment of the high limit.
●Set the high range. The range gauge shows the
setting position.
●Set the low range same as high range setting.
The limit value at the operation hardware neutralposition can now be adjusted using the
throttlelimiter.
1. Set “Center position” on the throttle limiter screen to Operate.
2. When the “Center position” rate is changed, the limit value at the operation hardware
neutral position can be adjusted.
●The limit value at the operation hardware neutral position when “Center position” was
changed to INH (at conventional operation) is the center value between “High side range”
and “Low side range”.
●When “Center position” was switched from INH to Operate, the “Center position” rate is reset
to the center value between “High side range” and “Low side range”
●The “Center position” rate can be set between “High side range” and “Low side range”.
Range gauge Rate adjust button Control selection
button
