48
Response adjustment
1. Touch the setting button corresponding to
the stick whose response you want to adjust.
Adjustment buttons appear on the right-
hand side of the stick setup screen.
2. Use the adjustment buttons to adjust the
response.
Initial value: 4
A d j u s t m e n t r a n g e : 1 ~ 1 6 ( W h e n t h e
adjustment value is large, the response
becomes slow.)
How to Calibrate
1. Choose the stick to calibrate right and left.
2. The stick is set at neutral and the [neutral]
button is pushed.
3. The stick is held at full right and full bottom
(diagonal) the [Right/Bottom] button is
pushed.
4. The stick is held at full left and full top
(diagonal) the [Left/ Top] button is pushed.
● Touch the [Stick Setting] button at the H/W Setting
Menu to call the setup screen shown below.
● Touch the [Calibration] button at the H/W Setting
Menu to call the setup screen shown below.
●Return to H/W Setting Menu
● Group/single mode switching (Gr./Sngl)
(For more information, see the description at the back of this manual.)
Hysteresis adjustment
1. Touch the setting button corresponding to
the stick whose hysteresis you want to adjust.
Adjustment buttons appear on the right-
hand side of the stick setup screen.
2. Use the adjustment buttons to adjust the
hysteresis.
Initial value: 1
A d j u s t m e n t r a n g e : 0 ~ 3 2 ( W h e n t h e
adjustment value is large, the hysteresis value
becomes large.)
●Return to H/W Setting Menu
*Please do not press the stick too firmly in any direction when
doing the calibration.
*Check after calibration to make sure that neutral is 0% and
bottom right side will be +100%, and the top left side is
become -100%.
