21
4. Close the battery cover so that the wiring is
not pinched and lock the cover by pushing
downward.
5 . Close the side door.
Warning
Be careful to not drop the battery.
Never take out the battery from the T18MZ
transmitter while the LED monitor is blinking.
* Internal settings and memories can be destroyed.
* Do not use the transmitter if a “Backup Error” warning oc-
curs. Send it to the Futaba Service Center to be checked.
Don't pull battery wiring.
*When it short-circuits, there is danger of explosion ignition.
Back lid
The charging connector, earphone jack, and S.BUS
setting connector, charge LED are accessed by
opening the transmitter rear cover as shown in the
figure.
[How to open back lid.]
1. Open the transmitter rear cover as shown in
the figure.
2. House the rear cover by pushing it into the
transmitter.
