Futaba 18MZ 2.4GHz - Manual (Page 68)

68
CH H-4/H-4X Swash All Other
1 Aileron Aileron
2 Elevator Elevator
3 Throttle Throttle
4 Rudder Rudder
5 Gyro Gyro
6 Pitch Pitch
7 Governor Governor
8 Elevator2 Governor2
9 GYRO2 GYRO2
10 GYRO3 GYRO3
11 Governor2 Needle
12 Needle AUX5
13 AUX4
14 AUX3
15 AUX2
16 AUX1
DG1
SW
DG2
CH H-4/H-4X Swash All Other
1 Aileron Aileron
2 Elevator Elevator
3 Throttle Throttle
4 Elevator2 Rudder
5 Pitch Pitch
6 Gyro Gyro
7 Governor Governor
8 Rudder Governor2
9 GYRO2 GYRO2
10 GYRO3 GYRO3
DG1
SW
DG2
Helicopter
●FASSTest 18CH / FASST MULTI / FASST 7CH / S-FHSS
●FASSTest 12CH
FASST 7CH S-FHSS FASST
est 18CH F
ASST MUL
T
The output CH of each
system
FASST
est 12CH
The output CH of each
system
