156
Reset
Linear curve adjustment
Rate A and Rate B can be adjusted separately or
simultaneously.
[Setting modes]
*[Separate] mode: Rates are adjusted
separately.
*[Combined] mode: Rates are adjusted
simultaneously.
[Setting method]
1. Select the setting mode.
2. Touch the Rate A or Rate B button.
3. Use the adjustment buttons to set the rate.
*Initial value: +100.0%
*Adjustment range: -200.0~+200.0%
The curve can also be offset horizontally in the
vertical direction and the rate reference point can
be offset to the left or right.
[Offsetting the curve horizontally in the vertical
direction]
1. Touch the Offset button.
2. Use the adjustment buttons to move the
curve horizontally up and down.
*Initial value: +0.0%
[Offsetting the rate reference
point to the left or right]
1. Touch the X Offset button.
2. Use the adjustment buttons to
move the reference point to the
left or right.
*Initial value: +0.0%
Setting by curve type
When the curve type is selected as described above, adjustment buttons corresponding to the curve type
appear on the original screen. Adjust each curve as described below.
(Linear curve)
(Rate adjustment buttons)
●Return to initial value
