80
●Return to Linkage Menu
●to [SWAP]
● Touch the [Function] button in the Linkage
Menu to call the setup screen shown below.
Function Channel assignment for each function can be changed to suit your needs.
When you select model and wing (swash) types,
you will find that the optimized combinations of
servo output channels and functions have been
already preset. If you would like, on the function-
setting screen of the linkage menu, you can freely
change combinations of servo output channels,
functions (aileron, elevator, etc), and input
controllers (sticks, switches, trim levers and trim
switches). You can also assign the same function to
multiple servo output channels such as assigning
elevator function to CH2 and CH3.
(The display screen is an example. The screen depends on the model type.)
Function change
1. Touch the function button of the channel
you want to change to call the function list.
2. Select the function you want to change.
3. Touch [Yes]. The display returns to the original
screen. (When you want to cancel function
change, touch [No].)
*Multiple channels can be assigned to 1 function.
*Multiprop1,2 is an optional object for Multiprop decoders.
FASSTest 18CH---1-12CH
FASSTest 12CH---not set
FASST MULTI ---11,12CH
FASST 7CH ---not set
S-FHSS ---not set
DG1, DG2 (switch channels)
These two channels can be used as switch (On/
Off) channels. You can freely change combinations
between servo output channels and input controllers
(sticks, switches, trim levers and trim switches).
Channel restrictions by a System Type
FASSTest 18CH---16 CH+2 Switch
FASSTest 12CH---10 CH+2 Switch
FASST MULTI ---16 CH+2 Switch
FASST 7CH --- 7 CH
S-FHSS --- 8 CH
Operation control change
1. Touch the control button of the channel
you want to change. A Control select
screen (stick, switch, knob, trim lever, etc.) is
displayed.
2. Select the control you want to operate.
3. Touch [Close]. The display returns to the
preceding screen.
*The same control can be assigned to multiple channels.
