52
Procedure for changing S.BUS servo setting
1. Select [S.BUS Servo] of the System Menu.
2. Wire the servo as shown in the figure above.
3. Press [Recall]. The ID and current setting of
that servo are displayed.
4. When multiple servos are connected change
[INH] at the right side of the ID number on the
screen to [ACT] and enter the ID of the servo
you want to set.
5. Set each item. (Please see the next page.)
6. Press [Write]. The settings are changed.
S.BUS Servo S.BUS servo setting
An S.BUS servo can memorize the channel
and various settings itself. Servo setting
can be performed on the T18MZ screen
by wiring the servo as shown in the figure.
● Call the following setting screen by pressing the
[S.BUS Servo] button in the System Menu.
●Return to System Menu
●Servo ID number
Individual ID numbers are memorized for your
S.BUS servos in your T18MZ. When a servo is
used (as shown at the right), the servo ID number is
automatically read by the transmitter.
If you use multiple S.BUS servos and do not want
to change the settings on all that are mounted in a
fuselage, only the desired servo in the group can be
set by entering the ID of that specific servo.
* S9070SB cannot be arranged by T18MZ.
* With S.BUS servos of use, there are a function which can be used, and an impossible
function and a display screen changes.
(Only the function which can be used by a servo is displayed.)
