83
●Return to Linkage Menu
● Touch the [Servo Reverse] button in the Linkage
Menu to call the setup screen shown below.
Servo Reverse Use to reverse the servo throw direction.
(The display screen is an example. The screen depends on the model type.)
Servo Reverse changes the direction of an
individual servo’s response to a control stick
movement.
For CCPM helicopters, be sure to read the
section on Swash AFR before reversing any servos.
With CCPM helicopters, always complete your
servo reversing prior to any other programming.
If you use pre-built Airplane/Sailplane functions
that control multiple servos, it may be confusing
to tell whether the servo needs to be reversed or a
setting in the function needs to be reversed. See the
instructions for each specialized function for further
details. Always check servo direction prior to every
Servo reversing procedure
After setting up a new model, be sure to
define all special menus. Be sure that all servos
are plugged into the proper receiver channels.
Now, determine whether you need to reverse any
channels by moving each stick and observing the
corresponding movement in the model’s controls.
1. Touch the desired channel’s Setting button
to choose the proper direction for the servo
2. Touch “Yes” in the next screen.
3. Repeat for each servo needing reversal.
When done, touch “Servo Reverse” to return to
the Linkage Menu.
flight as an additional precaution to confirm proper
model memory, hook ups, and radio function.
WARNING
Before a flight, it always check that your
models servo operation, the direction of control
surfaces, and switch setup are correct.
Default setting of the motor channel is always
reverse.
