Futaba 18MZ 2.4GHz - Manual (Page 150)

150
Gyro Mixing
It is mixing only for a Gyro in the case of using a
Futaba GY series Gyro.
Sensitivity and operational mode (Normal mode/GY mode)
can be set up for three Gyros for each condition, respectively.
Note: Always set both (ACT) and (Trim) for the [Gyro]
function.
● Return to Gyro Menu
● Return to Model Menu
● Touch the [Gyro] button in the Model Menu
to call the setup screen shown below.
● A setup of the mode of 3 Gyros and Rete
can be performed on this screen.
● A detailed setup of each Gyro can be
performed on this screen.
Setting method
● Touch the [INH] button of the rate to be used and
display [ON].
● When you want to set the same settings to other
conditions, select the group mode (Gr.). When
you want to add settings to the selected condition
only, select the single mode (Sngl).
● Three rates can be switched for each condition.
(Rate 1/Rate 2/Rate 3)
● A fine tuning VR can be set.
Setting example
● Normally, it is convenient to preset high
sensitivity (Rate 1) and low sensitivity (Rate
2) when either the AVCS mode or Normal
mode is used.
●Selects the selector switch.
●Adjusts the gyro sensitivity by rate.
●Selects [AVCS] or [Nor].
●Select the type of gyro used.
