43
Model 1
85%
Display
- +
- +
30Min.
1Min.
Auto Power off time
Backlight decrease
Back color Touch screen
Backlight decrease time
Backlight
TEXT TEXT TEXT TEXT TEXT
Cal.
Auto power off time setting
The function to prevent a battery from
discharging by failure of the power supply of
a transmitter to erase.
1. Adjust the auto power off time with the left
and right side buttons.
*When the time the transmitter is inactive reaches the set
time, the power is turned off automatically. This time can be
set up to 1 hour in 10 minutes increments. The auto power
off function can also be deactivated.
*An audible alarm is sounded and an alarm screen is
displayed from 3 minutes before auto power off and
the time remaining until auto power off is displayed.
When a stick or switch is operated while the alarm
screen is being displayed, the alarm is cleared and
the display is returned to the home screen.
Backlighting brightness adjustment
1. Adjust the backlighting brightness with the
left and right side buttons.
*When the right side button is touched, the backlighting
becomes brighter. When the left side button is touched, the
backlighting becomes darker.
Backlight decrease brightness adjustment
1. Adjust the backlight decrease brightness with
the left and right side buttons.
*When the right side button is touched, the backlighting
becomes brighter. When the left side button is touched, the
backlighting becomes darker.
*It cannot be made brighter than Backlighting brightness
adjustment.
Display LCD screen adjustment and auto power off setting
The following LCD screen adjustments and auto
power off setting are possible:
● Auto power off time setting
● Backlighting brightness adjustment
● Background color change
● Touch panel screen calibration correction
● Touch the [Display] button in the System Menu to
call the setup screen shown below.
●Return to System Menu
Backlight decrease time
You can set a time period to decrease the LCD
backlight. This function counts the period that
the touch panel has been not operated. This
time can be set by ten-second steps. You can
also turn off the backlight decrease” if you
like.
*The backlight consumes a large amount of power. We
recommend you to turn off the backlight by setting the
backlight power-off time to about one minute.
Background color
1. Touch the button of the color you want to
change.
*There are five background colors.
Touch screen calibration
This function adjusts the location of touch
panel. Touch "Calibration" button and then
press "Yes", the calibration screen will pop
up. Touch the center of the cross hair cursor
on the screen with the stylus pen. As soon as
the system recognizes the position, the cursor
will move on to the next position. Repeat this
procedure as long as the cursor moves to next
position. You will do this five times. Calibration
will be carried out based on the five positions.
Disappearance of the cross hair cursor means
the calibration has been completed. Touch
any point on the screen to return to the
previous screen.
*In ordinary operation, this calibration is not necessary. If
you notice the touch panel is not functioning correctly after
long use, we recommend you to carry out this calibration.
