72
●Return to Linkage Menu
● Touch the [Model Type] button in the Linkage Menu to
call the setup screen shown below.
● When a data change will occur, the confirmation
screen of data initialization menu will be displayed.
A push on [yes] will initialize data and allow changes.
A push on [no] will stop data changes.
Model Type This function allows you to select the model type from among airplane,
helicopter, and glider.
(The display screen is an example. The screen depends on the model type.)
Seven types of main wings and three types
of tail wings are available for airplanes. Eight
swash types are available for helicopters. Seven
types of main wings and three types of tail wings
are available for gliders. Functions and mixing
necessary for each model type are set in advance at
the factory.
Note: The Model Type function automatically
selects the optimal output channels, control
functions, and mixing functions for the chosen model
type. When the Model Type Selection is accessed, all
of settings in the active model are cleared. Be sure
that you don’t mind losing this data, or back it up to
memory using the copying functions.
Model type selection
1. Set the Model type, Wing type, Tail type, or
Swash type by using the appropriate button.
2. Set the type you choose by touching [Yes] at
the confirmation screen. (When you want to
cancel model type selection, touch [No].)
Date changes after a swash type change
Data that has been set may change if the
swash type of your helicopter is changed.
(Refer to the following table) When data is
changed the [swash setting] screen is initialized.
Before After Data taking over
H-1, H-2, HE3,
HR3, HN3, H-3
H-1, H-2, HE3,
HR3, HN3, H-3
OK
H-4, H-4X H-4, H-4X OK
H-1, H-2, HE3,
HR3, HN3, H-3 H-4, H-4X
NG
H-4, H-4X
H-1, H-2, HE3,
HR3, HN3, H-3
NG
