57
Chapter 4 Installing the Setup Software
4
3. Enter the “Read error code” from the keyboard. The code can be changed as
desired (within 8 characters).
Normally, the initial setting (ERROR) should be used as provided.
If a blank is specified for the setting, the BL-700 will not send the read error
code.
4. Click “Trigger input setting” to set the trigger input.
• Read mode
➮ P.35 to 38
• Data transmission trigger
➮ P.34
• Double reading prevention time
➮ P.35 to 36
• Decoding match count
➮ P. 32
• Additional data function
➮ P.48 to 49
• Read error code
➮ P.89
Trigger input setting
Set the trigger input, scanning method and trigger ON/OFF command.
1. For the scanning method, select either “Level signal trigger” or “One-shot signal
trigger”. If “One-shot signal trigger” is selected, the scanning time setting menu
also appears.
Set the scanning time to a number from 1 to 255 (100 ms to 25.5 s).
Tips
