Chapter 5 Serial Communication
96
5
Function
Command being
Response
Description
Error
sent
code
Change
WCm42n
OK
m=0 to 3: Codes 1 to 4 00, 02,
Confirm
RCm42
42n
n=0: Disable
03, 04,
1: Enable
05, 07,
Change
WCm43n
OK
m=0 to 3: Codes 1 to 4 14
Confirm
RCm43
43n
n=0:Output in 13 digits
1:Output in 12 digits
Change
WCm44n
OK
m=0 to 3: Codes 1 to 4
Confirm
RCm44
44n
n=0: Disable
1: Enable
Change
WCm51n
OK
m=0 to 3: Codes 1 to 4
Confirm
RCm51
51n
n=0: Disable
1: Enable
Change
WCm83n
OK
m=0 to 3: Codes 1 to 4
Confirm
RCm83
83n
n=0: Disable
1: Enable
Change
WCm84n
OK
m=0 to 3: Codes 1 to 4
Confirm
RCm84
84n
n=0: Forward
1: Reverse
Change
WCm85nn
OK
m=0 to 3: Codes 1 to 4 00, 02,
Confirm
RCm85
85nn
nn=01 to 32
03, 04,
: Effective digits
05, 09,
Change
WCm86nn
OK
m=0 to 3: Codes 1 to 4 14
Confirm
RCm86
86nn
nn=01 to 32
: Starting digit
Change
WCm81n
OK
m=0 to 3: Codes 1 to 4 00, 02,
Confirm
RCm81
81n
n=0: Disable
03, 04,
1: Enable
05, 07,
Change
WCm82n
OK
m=0 to 3: Codes 1 to 4 14
Confirm
RCm82
82n
n=0: Forward
1: Reverse
EAN/UPC(A•E)
Reading JAN 13
digits
EAN/UPC(A•E)
No. of UPC-A
output digits
EAN/UPC(A•E)
Adding “0” to UPC-
E system code
CODE128 Checking
double character
start pattern
➮ See p. 32.
Setting max. code
length output
function
Setting direction for
max. code length
output
Setting effective
digits for max. code
length output
Setting starting digit
for max. code
length output
Setting label
orientation speci-
fied reading
Setting orientation
for orientation-
specified reading
