Chapter 3 Functions for Reading Operation
36
3
Example
Suppose that the following codes are specified:
Code 1: CODE39, 10 digits
Code 2: EAN/UPC, 13 digits
Code 3: None
Code 4: CODE39, 8 digits
When the unit successfully reads all 3 types of codes:
When the unit fails to read Code 1 (CODE39, 10 digits)
When the unit fails to read Code 1 (CODE39, 10 digits) and Code 4 (CODE39, 8
digits)
• When the same type of data having the same digits is specified to all Codes 1
to 4, the unit sends the data in the reading order.
Example
Suppose that the following codes are specified:
Code 1: CODE39, 7 digits
Code 2: CODE39, 7 digits
Code 3: CODE39, 7 digits
Code 4: CODE39, 7 digits
Note: The unit cannot read the bar code having the same content twice while
trigger input turns on once.
Header ABCDE12345 KEYENCE1 Delimiter 4901234567894
, ,
Header ERROR KEYENCE1 Delimiter 4901234567894
, ,
Header ERROR ERROR Delimiter 4901234567894
, ,
Header ABCD123 XYZ3333 1234567 Delimiter
, , , ,
KEYENCE
