Chapter 4 Installing the Setup Software
54
4
4.2.3 Outline of operation
This section describes the basic operations of the BL setup software.
To enter settings, place the mouse pointer on the item to be changed, and click the
left mouse button.
■ Clicking on • • • (tabs)
Used to select the item to be changed.
■ Clicking on ● ●
(radio button)
Used to select any of several options.
The selected item is marked with
● ●
.
■ Clicking on a ■ ■
(box)
Used to select whether to enable or disable this function.
To enable this function, the
■ ■
mark is checked with “ ”. (For the Windows Ver. 3.1,
it is checked with “x”.)
■ Clicking on ▼ (arrow)
Used to select any of several options.
•
▲
Mouse pointer
