KEYENCE BL-700 Series - Manual (Page 113)

99
Chapter 5 Serial Communication
5
■ Setting Communication Parameters 1
Function Command being Response Description Error
sent code
Setting baud rate Change WP35n OK N=5: 38400 bps 00, 02,
Confirm RP35 035n 6: 31250 bps 05, 08,
7: 19200 bps 14
0: 9600 bps
1: 4800 bps
2: 2400 bps
3: 1200 bps
4: 600 bps
Change WP30n OK n=0: 7 bits 00, 02,
Confirm RP30 30n 1: 8 bits 05, 07,
Change WP31n OK n=0: Disable 14
Confirm RP31 31n 1: Enable
Setting parity type Change WP32n OK n=0: Even
Confirm RP32 32n 1: Odd
Setting Stop bit Change WP33n OK n=0:1 bit
Confirm RP33 33n 1: 2 bits
Change WP22n OK n=0: Disable
Confirm RP22 22n 1: Enable
Change WP34n OK n=0: Disable
Confirm RP34 34n 1: Enable
Change WP44nn OK nn=01 to 31 00, 02,
Confirm RP44 44nn 05, 09,
14
Setting data bit
length
Setting parity check
* To set the parity
type, use the
command below.
Setting RTS/CTS
handshaking
Setting RS-485
multi drop link
Setting ID No. for
RS-485 multi drop
link.
